FS-A79 |
|
PICMG 1.3 Supports
8th & 9th generation Intel® Core
Desktop
|
|
 |
|
8th
& 9th generation
Intel® Core™ Desktop processor in LGA 1151
Intel®
Q370 chipset, two DDR4
2666 MHz up to 32GB,
Support
VGA, DVI, LVDS, DisplayPort, HD audio,
1 x Intel®
Giga LAN,
1 x Intel®
Giga PHY LAN, 2 x RS232/422/485,
4 x RS232, 4
x USB2.0,
6 x USB3.0, 8-bit GPIO,
SMBus, 3
x SATAIII with RAID, Mini-PCIe socket.
|
| |
|
|
|
FS-A78 |
|
PICMG 1.3 Supports 4th generation desktop Intel® Core i7/i5/i3
|
|
 |
|
4th generation
Intel® Core™ i7 / i5 / i3 Desktop processor in LGA 1150
Intel®
Q87 Express chipset, DDR3/DDR3L 1333/1600 MHz up to 16GB,
Support
VGA, DVI , LVDS, Display port , HD audio,
1 or 2 x Intel®
Giga LAN,
1 x RS232/422/485, 5 x RS232, 4
x USB2.0, 6 x USB3.0, LPT, 8-bit GPIO, IrDA,
SMBus, 4
x SATAIII with RAID, Mini-PCIe socket.
|
| |
|
|
|
FS-A77
|
|
PICMG
1.3 Supports 3rd generation mobile Intel® Core i7/i5/i3 |
|
|
|
3rd generation Intel®
Core™ i7 / i5 / i3 Mobile processor in PGA 988B
Mobile Intel®
QM77 Express chipset, DDR3 1066/1333/1600 MHz up to 16GB,
Support DVI,
LVDS, HD audio, 2 x Giga LAN, 4 x SATAII, 2 x SATAIII
1 x RS232/422/485, 5 x RS232,
4 x USB2.0, 4 x
USB3.0, 8-bit GPIO, SMBus
2 x Mini-PCIe sockets .
|
| |
|
|
|
FS-A76
|
|
PICMG
1.3 Supports 3rd generation desktop Intel® Core i7/i5/i3 |
|
|
|
3rd generation Intel®
Core™ i7 / i5 / i3 Desktop processor in LGA 1155
Intel® Q77 Express chipset,
DDR3 1066/1333 MHz up to 16GB,
Support VGA,
DVI , HD audio, 2 x Intel®
Giga LAN,
1 x RS232/422/485, 5 x RS232,
4 x USB2.0, 4 x
USB3.0, LPT, 8-bit GPIO, SMBus, 4 x SATAII, 2 x SATAIII
with RAID, 2 x Mini-PCIe sockets.
|
| |
|
|
|
FS-A75 |
|
PICMG
1.3 Supports 2nd generation mobile Intel® Core i7/i5/i3 |
|
|
|
2nd generation Intel®
Core™ i7 / i5 / i3 Mobile processor in PGA 988B
Mobile Intel®
QM67 Express chipset, DDR3 800/1066 MHz up to 16GB,
Support VGA,
LVDS, HD audio, 2 x Intel®
Giga LAN,
1 x RS232/422/485, 5 x RS232,
8 x USB2.0, LPT, 8-bit GPIO, SMBus
Mini-PCIe socket, 6 x SATA
with RAID
|
|
|
|
|
|
FS-A74
|
|
PICMG
1.3 CPU Card supports desktop Intel® Core i7 / i5 / i3
|
|
|
|
2nd generation Intel®
Core™ i7 / i5 / i3 Desktop processor in LGA 1155
Intel® Q67 Express chipset, DDR3
1066/1333 MHz up to 16GB,
Support VGA,
DVI, HD audio, 2 x Intel®
Giga LAN, 1 x SIM
1 x RS232/422/485, 5 x RS232,
8 x USB2.0, LPT, 8-bit GPIO, SMBus
2 x Mini-PCIe sockets, 6 x SATA
with RAID
|
|
|
|
|
|
FS-A73 |
|
PICMG
1.3 CPU Card supports mobile Intel® Core i7 / i5 / i3 |
|
|
|
Intel®
Core™ i7 / i5 / i3 Mobile processor in PGA 988A
Mobile Intel®
QM57 Express chipset, DDR3 800/1066 MHz up to GB,
Support VGA,
24-bit LVDS, DVI, HD audio, 2 x Intel®
Giga LAN
1 x RS232/422/485, 5 x RS232, 8 x USB2.0, 6 x SATAII
Mini-PCIe socket,
SMBus, 8-bit GPIO, LPT, IrDA
|
|
|
|
|
|
FS-A72 |
|
PICMG
1.3 CPU Card supports Intel® Core 2 Quad / Core 2 Duo |
|
|
|
Intel® CoreTM
2 Duo / CoreTM 2
Quad processor, 800/1066/1333MHz FSB
Intel®
Q45 & ICH10DO chipset, DDRIII 800/1066MHz up to 4GB,
Onboard VGA, Onboard 2 x Intel® Gigabit LAN,
6 x SATA with RAID 0/1/5/10
RS232/422/485, USB 2.0, 8-bit
GPIO, LPT, FDD,
IrDA |
| |
|
|
|
FS-A71 |
|
PICMG
1.3 CPU Card supports Intel® Core 2 Duo mobile CPU |
|
|
|
Intel® CoreTM 2 Duo
( Merom )processor @ 800 MHz FSB
Intel® GME965
& ICH8M, DDRII 533 / 667
MHz up to 3GB, Onboard VGA
24-bit Dual
Channel LVDS, 2 x Mini-PCI sockets, HDTV
Onboard 2 x Intel® Gigabit LAN,
HD Audio, CF socket
RS232/422/485, 6 x USB 2.0, 8-bit GPIO, LPT, FDD,
IrDA |
| |
|
|
|
FS-A70 |
|
PICMG
1.3 CPU Card supports Intel® Core 2 Quad / Core 2 Duo |
|
 |
|
Intel® CoreTM
2 Duo / CoreTM 2
Quad processor, 533/800/1066MHz FSB
Intel®
Q965 & ICH8DO chipset, DDRII 533/667/800MHz up to 4GB,
Onboard VGA, Onboard 2 x Intel® Gigabit LAN,
6 x SATA with RAID 0/1/5/10
RS232/422/485, USB 2.0, 8-bit
GPIO, LPT, FDD, IrDA, Mini-PCI |
| |
|
|
|
|
|
|
|
|
Intel® Atom
N270 ( 1.6 GHz ) processor @ 533 MHz FSB
Intel® 945GSE
& ICH7M, DDR2 SO-DIMM up to 2GB, Onboard VGA,
18-/24-bit Dual Channel LVDS or
DVI,
2
x Gbit LAN, AC97 audio,
1 x IDE, 2 x
SATA, 6 x USB 2.0, 5 x
RS232, 1 x RS232/422/485, 1 x LPT,
GPIO, HDTV, 1 x
Mini PCIe, 1 x Mini PCI, 1 x Compact Flash Type II socket
|
| |
|
|
|
FS-97E |
|
PICMG
1.0 supports Intel® Penryn CPU @ 1066 MHz FSB |
|
|
|
Support Intel®
Penryn CPU with FSB up to 1066MHz, Intel® GM45
& ICH9M,
DDRIII 800/1066
SO-DIMM up to
8GB, VGA, LVDS, IDE, 5
x SATA, HD Audio,
CF,
GPIO, LPT, HDTV, IrDA, RS232/422/485,
FDD, USB, SMBus
1 x DVI (optional),
2 x Intel® Gigabit LAN (optional),
1 x Mini PCI (optional),
2 x PCI
Express Mini Card socket (optional) |
| |
|
|
|
FS-97D |
|
PICMG
1.0 supports Intel® Core 2 Quad CPU @ 1333 MHz FSB |
|
|
|
Intel® CoreTM
2 Duo / CoreTM 2
Quad, 800/1066/1333MHz FSB
Intel®
Q35 & ICH9DO chipset, DDRII 667/800MHz up to 4GB,
Onboard VGA, Optional DVI or LVDS, 2 x Intel® Gigabit LAN,
6 x SATA with RAID 0/1/5/10, RS232/422/485, USB 2.0, 8-bit
GPIO, LPT,
FDD, IrDA, Mini-PCI |
| |
|
|
|
FS-97C |
|
PICMG
1.0 CPU Card supports Intel® Core 2 Duo Mobile |
|
|
|
Intel® CoreTM 2 Duo / CoreTM Duo processor, 533 / 667 MHz FSB
Intel® 945GME and
ICH7M chipset
DDRII 533 / 667
MHz up to 3GB, Onboard VGA, HDTV
18-bit Dual
Channel LVDS & DVI interface
Onboard 2 x Intel® Gigabit LAN,
5.1 channel Audio
RS232/422/485, USB 2.0, 8-bit GPIO, LPT, FDD, IrDA
2 x Mini-PCI &
CompactFlash socket |
| |
|
|
|
|
|
PICMG 1.0 CPU Card supports Intel® Core 2 Duo
CPU |
|
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo processor, 533 / 800 / 1066 MHz FSB
Intel®
Q965 & ICH8DO chipset
DDRII 533 / 667/
800
MHz up to 4GB, Onboard VGA
Optional 24-bit Dual
Channel LVDS or DVI interface
Onboard 2 x Intel® Gigabit LAN,
6 x SATA with RAID 0/1/5/10
RS232/422/485, USB 2.0, 8-bit GPIO, LPT, FDD, IrDA, Mini-PCI |
| |
|
|
|
FS-97A |
|
Intel® Pentium
M Full-size PICMG CPU Card |
|
 |
|
Intel® Pentium M & Celeron M processor-based running up to 2GHz with
Intel® 855GME & ICH4, 2GB DDR SDRAM, 100 Mbps & Gigabit Ethernet port,
4 x USB 2.0, 2 x COM1 x Printer Port, AC97 3D Audio, CompactFlash Interface,
8-bit Digital I/O,
Mini-AGP socket, 24-bit LVDS |
|
|
|
|
|
BackToTop |
| |
Half-size ISA/PCI/PISA/PICMG1.3 CPU Card / Slot PC
|
|
|
|
|
HE-B73
|
Half-size
/ PICMG 1.3 SBC support Intel® Tiger Lake 11th generation H Processor |
 |
Support 11th Generation Intel®
Core™ i7, i5, i3, Xeon H-series Processor with 2 x DDR4 SO-DIMM up to 64GB. Mobile Intel®
QM580E/RM590E, onboard DisplayPort, internal DVI, VGA, and LVDS,
1 x Gigabit PHY LAN, 1 x 2.5Gigabit LAN, 2 x USB3.2 Gne2(Type E), 4 x USB2.0, 3
x Serial ATA3, GPIO, HD Audio, 1 x MiniPCIe slot with SIM slot (support mSATA),
1 x M.2 2280 Key M support PCIe Gen4 and SATA , 1 x M.2 2230 Key E for WiFi and
BT, 1 x PCIeX16, 1 x PCIeX4 or 4 x PCIeX1. |
| |
|
|
HE-B72
|
Half-size
/ PICMG 1.3 SBC support 6th generation Intel® Core™ i7 / i5 / i3 |
 |
Support 6th Generation Intel®
Core™ i7, i5, i3 H-series Processor with 2 x DDR4 SO-DIMM up to 32GB. Mobile Intel® QM170, onboard DisplayPort, CRT, DVI, LVDS,
1 x Gigabit PHY LAN, 1 x Gigabit LAN, 4 x USB3.0, 4 x USB2.0, 1 x Mini
PCIe slot(support mSATA), 1 x
Half Size MiniPCIe slot, 3 x Serial ATA3, GPIO ,LPC, HD Audio. |
| |
|
|
HE-B71
|
Half-size
/ PICMG 1.3 SBC support 4th generation Intel® Core™ i7 / i5 / i3 |
 |
Support 4th Generation Intel® Core™ i7, Core™ i5, Core™ i3 and Celeron CPU
with 2 x DDR3L SO-DIMM up to 16GB. Mobile Intel® QM87 Express, onboard
DisplayPort, CRT, DVI, LVDS, 2 x Gigabit LAN, 4 x USB3.0, 2 x USB2.0,
1 x Mini
PCIe slot (Optional support mSATA), 4 x Serial ATA3, GPIO,
LPC, HD Audio. |
|
|
|
HS-B70 |
Half-size
/ PICMG 1.3 SBC support 3rd and 2nd generation Intel® Core™ i7 / i5 / i3 |
|
|
3rd generation Intel® Core™
i7 / i5 / i3 Mobile processor in PGA 988B.
Mobile Intel®
QM77 Express, onboard VGA, LVDS & DVI, 16GB DDR3,
2 x Giga
LAN, 2
x USB 2.0, 4 x USB 3.0, 6 x COM,
4 x SATA, HD
Audio, GPIO, 1 x
Mini-PCIe sockets.
|
|
|
|
HS-774
|
PCI-bus
SBC support 3rd generation Intel®
Core™ i7 / i5 / i3 |
|
|
3rd generation Intel®
Core™ i7 / i5 / i3 Mobile processor in PGA 988B
Mobile Intel®
QM77 Express chipset, DDR3 1066/1333/1600 MHz up to 16GB,
Support DVI,
LVDS, HD audio, 2 x Giga LAN, 2 x SATAII, 2 x SATAIII
1 x RS232/422/485, 5 x RS232,
2 x USB2.0, 4 x
USB3.0, 8-bit GPIO, SMBus
2 x Mini-PCIe sockets, 1 x SIM
card socket
|
|
|
|
HS-773 |
PCI-bus
SBC support 2nd generation Intel®
Core™ i7 / i5 / i3 |
|
|
2nd generation Intel®
Core™ i7 / i5 / i3 Mobile processor in PGA 988B
Mobile Intel®
QM67 Express chipset, DDR3 800/1066 MHz up to 16GB,
Support DVI,
LVDS, HD audio, 2 x Giga LAN, 2 x SATAII, 2 x SATAIII
1 x RS232/422/485, 5 x RS232,
8 x USB2.0, SPDIF, 8-bit GPIO, SMBus
2 x Mini-PCIe sockets, 1 x SIM
card socket
|
|
|
|
|
HE-772 |
PCI-bus CPU Card
for Intel®
Atom Dual Core solution |
|
|
Half-size PCI-bus
Intel® Atom
D525 / D510 / D410 / N450 processor
DDR2 up to 2.0
/ 4.0 GB, Onboard LVDS, VGA, 3 x SATA
2
x Intel® Gigabit LAN, 6 x USB 2.0, 5 x
RS232, 1 x RS232/422/485,
LPT, GPIO,
SMBus, Mini-PCIe
socket, Compact Flash Type II socket
|
|
|
|
|
HS-771
|
Intel®
Penryn Half-size PCI-bus CPU card |
|
|
Half-size PCI-bus
Intel® CoreTM 2 Duo
processor with socket-P @ 667/800/1066 MHz FSB
Intel® GM45
& ICH9M, DDR3 800/1066 MHz up to 8GB
Onboard VGA, HDTV, 24-bit Dual
Channel LVDS, DVI-D
Mini-PCI
and PCI Express Mini card socket. 8-bit GPIO
Onboard 2 x Intel® Gigabit LAN,
HD Audio, 2 x COM
4 x SATA, SMBus, 8
x USB 2.0 ports |
|
|
|
HS-770
|
Intel® Pentium M / Celeron M
PCI CPU Card |
|
 |
Half-size PCI-bus Intel®
Pentium M / Celeron M with 400/533 MHz FSB.
Intel®
915GME & ICH6M chipset, 2 x DDRII DIMM
Support
24-bit LVDS, Onboard Dual Gigabit LAN and SATA
AC97 3D
Audio, support CompactFlash type-II
3 x RS232
& 1 x RS232/422/485 ports, 4 x USB 2.0 ports |
|
|
|
HE-875P |
Intel®
Atom PISA CPU Card |
|
 |
Intel® Atom
N270 ( 1.6 GHz ) processor @ 533 MHz FSB
Intel® 945GSE
& ICH7M, DDR2 SO-DIMM up to 2GB, Onboard VGA,
18-/24-bit Dual Channel LVDS or DVI,
2
x Gigabit LAN, AC97 audio,
1 x IDE, 2 x SATA, 6 x USB 2.0,
1 x
RS232, 1 x RS232/422/485, 1 x LPT,
GPIO, HDTV, 1 x Mini-PCI
socket, 1 x Compact Flash Type II socket |
|
|
|
HS-874P |
Intel®
Core 2 Quad / Core 2 Duo PISA CPU Card |
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop, 800/1066/1333 MHz FSB Intel®
Q35 & ICH9DO, DDRII 667/800 MHz up to 2GB
Onboard VGA,
Optional DVI or 24-bit LVDS interface
Onboard 1 x Intel® Gigabit LAN,
HD Audio, 4 x SATA with RAID
1 x RS-232/422/485 & 1 x
RS232, 4 x USB 2.0, IrDA, GPIO |
|
|
|
HS-873P |
Intel®
Penryn Half-size
PISA CPU card |
|
 |
Half-size PISA CPU card,
supports Intel®
Penryn CPU with FSB up to
1066MHz, Intel® GM45
& ICH9M, DDRIII 800/1066 SO-DIMM up to 8GB
VGA, 18/24-bit
dual channel LVDS, 3 x SATAII, HD Audio, 8-bit GPIO, LPT
HDTV, IrDA, PCI
Express Mini Card socket, 1 x RS232, 1 x RS232/422/485
DVI (optional),
2 x Intel® Gigabit LAN (optional) |
|
|
|
HS-872P |
Intel®
Core 2 Duo / Core Duo PISA CPU Card |
|
|
Intel® CoreTM
2 Duo / CoreTM Duo processor, 533 / 667 MHz FSB
Intel® 945GME
& ICH7M
DDRII 533 / 667
MHz up to 2GB, Onboard VGA
18-bit Dual
Channel LVDS & DVI interface, HDTV
Onboard 2 x Intel® Gigabit LAN,
5.1 channel Audio
RS232/422/485, USB 2.0, 8-bit GPIO, LPT, FDD, IrDA
1 x Mini-PCI &
CompactFlash socket |
|
|
|
|
|
.jpg)
|
Half-size PISA-bus Onboard Intel® Mobile Celeron 1.2GHz 256KB cache
uFCPGA CPU with Intel® 82852GM & ICH4, 1GB DDR SDRAM,
Gigabit Ethernet port, 2 x USB 2.0, 2 x COM, 1 x Printer Port
AC97 3D Audio, CompactFlash Interface, 8-bit Digital I/O,
24-bit Dual LVDS |
|
|
|
|
|
|
|
Half-size PISA-bus Onboard Intel® ULV Celeron M 600MHz
uFCBGA CPU with Intel® 852GM & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port, 2 x USB 2.0, 2 x COM, 1 x Printer Port
AC97 3D Audio, CompactFlash Interface, 8-bit Digital I/O,
24-bit Dual LVDS |
|
|
|
|
|
|
Half-size PISA-bus Intel® Pentium M & Celeron M, processor-based running
up to 2 GHz with Intel® 855GME & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port, 2 x USB 2.0, 2 x COM , 1 x Printer Port
AC97 3D Audio, CompactFlash Interface, 8-bit Digital I/O,
24-bit Dual LVDS |
|
|
|
HS-870SCM6 |
Intel®
ULV Celeron M 600 MHz ISA CPU Card |
|
|
Half-size ISA-bus Onboard Intel® ULV Celeron M 600MHz
uFCBGA CPU with Intel® 852GM & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port, 2 x USB 2.0, 2 x COM, 1 x Printer Port
AC97 3D Audio, CompactFlash Interface, 8-bit Digital I/O,
24-bit Dual LVDS |
|
|
|
HS-870S |
Intel®
Pentium M ISA CPU Card |
|
|
Half-size ISA-bus Intel® Pentium M & Celeron M, processor-based running
up to 2GHz with Intel® 855GME & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port, 2 x USB 2.0, 2 x COM, 1 x Printer Port
AC97 3D Audio, CompactFlash Interface, 8-bit Digital I/O,
24-bit Dual LVDS |
|
|
| |
|
BackToTop |
Industrial 5.25" Embedded Miniboard
|
|
|
|
|
|
|
|
|
LS-57A |
|
|
5.25"
Desktop Miniboard supports Intel®
12th /
13th / 14th Core
Processor,
FCLGA1700 package |
|
 |
|
|
Intel® 12th & 13th & 14th Core™
Desktop
Processor,
FCLGA1700 package
2 x DDR5
SO-DIMM 4800
MHz up to 64GB,
Integrated DP, LVDS,
HDMI, HD audio, 4 x Gigabit ethernet,
3 x SATA3
2
x RS232/422/485, 2 x RS232,
2
x USB2.0, 5 x USB3.2 Gen2,
1 x USB3.2 Gen1,
8-bit GPIO, 1 x Mini-PCIe socket, 1 x SIM
slot, 2 x M.2 (Key M), 1
x M.2 (Key E)
Standard 24-pin ATX P/S or
DC 9V ~ 28V input
|
|
|
|
|
|
|
LS-579
|
|
|
5.25"
Desktop Miniboard supports Intel®
6th / 7th Core i7 / i5 / i3 S-series
and Xeon®
E3-1200 v5 / v6 Processor,
FCLGA1151 package |
|
 |
|
|
Intel® 6th & 7th Core™ i7 / i5 / i3
and Xeon®
E3-1200 v5 / v6
Processor,
FCLGA1151 package
2 x DDR4
SO-DIMM 1866/2133
MHz up to
32GB,
Integrated
VGA, DP, LVDS,
HDMI, HD audio, 4 x Gigabit ethernet,
4 x SATA3
2
x RS232/422/485,
4 x RS232,
4 x USB2.0, 6 x USB3.0, 8-bit GPIO,
2 x Mini-PCIe sockets, 1 x SIM socket, 2 x M.2 (Key M), 1
x M.2 (Key E)
Standard 24-pin ATX P/S or
DC 9V ~
35V input
|
|
|
|
|
|
|
LE-578
|
|
|
5.25" SBC Supports Intel®
Apollo Lake Series Processor |
|
|
|
|
Intel® Apollo Lake Series
processor
2 x DDR3L
SO-DIMM 1866 MHz up to
8GB,
Onboard
DP, LVDS,
HDMI, HD audio, 4 x Gigabit ethernet,
2 x SATA3
2
x RS232/422/485,
4 x RS232,
4 x USB2.0, 4 x USB3.0, 8-bit GPIO,
2 x Mini-PCIe sockets, 1 x SIM socket, 1 x SD Card
Standard 24-pin ATX P/S or
DC
6V ~
35V input
|
|
|
|
|
|
|
LE-577
|
|
|
5.25"
Embedded Miniboard supports 7th Gen
Intel®
Core™
/ Xeon®
H-series Processor |
|
|
|
|
Intel® 7th Gen Intel®
Core™ / Xeon® H-series
processor
2 x DDR4
SO-DIMM 2133 MHz up to 32GB,
Integrated VGA,
DP, LVDS,
HDMI, HD audio, 4 x SATA3, 4 x USB2.0, 6 x USB3.0,
3 x Gigabit ethernet,
1 x Gigabit PHY ethernet,
2
x RS232/422/485,
4 x RS232,
2 x Mini-PCIe sockets, 1 x
PCIe X 16 slot
(Only support 8 lane),
2 x M.2 (Key M), 1 x M.2 (Key E), 1 x SIM socket, 8-bit GPIO,
Standard 24-pin ATX P/S or
DC
9V ~
35V input
|
|
|
|
|
|
|
LS-576
|
|
|
5.25" SBC Supports 3rd generation mobile Intel® Core i7 /i5 /i3
|
|
|
|
|
3rd generation Intel® Core™ i7 / i5 / i3 Mobile processor
Mobile Intel® QM77 Express chipset, DDR3 1066/1333/1600 MHz up to 16GB,
Onboard VGA,
LVDS, DVI, HD audio, 6 x Gigabit ethernet, 6 x SATA
1 x RS232/422/485, 5 x RS232, 1 x Parallel,
4 x USB2.0, 4 x USB3.0, 8-bit GPIO,
2 x Mini-PCIe sockets, 1 x SIM socket
Standard 20-pin ATX P/S or Full range DC 9V ~ 24V input
|
|
|
|
|
|
|
LE-575
|
|
|
5.25" Intel® Atom platform with 4 x Intel® Giga LAN
|
|
|
|
|
Intel®
Atom N270 processor @ 533MHz FSB
Intel®
945GSE & ICH7M chipset
DDR2 up
to 2GB, VGA, DVI, LVDS and HDTV
Onboard
4 x Intel® Gigabit LAN,
IDE, SATA, USB2.0, COM
CompactFlash and Mini-PCI / PCI socket , Audio
20/24-pin ATX or 9~24V DC-IN
|
|
|
|
|
|
|
LS-574
|
|
|
5.25" SBC Supports 2nd generation mobile Intel® Core i7 /i5 /i3
|
|
|
|
|
2nd generation
Intel® Core™ i7 / i5 / i3 Mobile processor in PGA 988B
Mobile Intel®
QM67 Express chipset, DDR3 800/1066 MHz up to 16GB,
Support
VGA, LVDS, HD audio, 6 x
Intel® Giga LAN,
1 x RS232/422/485, 5 x RS232,
8 x USB2.0, LPT, 8-bit GPIO, SMBus
2 x Mini-PCIe sockets, SIM socket, 6 x SATA with RAID
DC 9V ~ 24V full
range input or standard 20-pin ATX P/S
|
|
|
|
|
|
|
LS-573
|
|
|
5.25" Intel® Penryn platform with 6 x Intel® Giga LAN
|
|
|
|
|
Intel® CoreTM 2
Duo processor with socket-P @ 667/800/1066 MHz FSB
Intel®
GM45 & ICH9M, DDR3 800/1066 MHz up to 8GB
Onboard
VGA, HDTV, 24-bit Dual Channel LVDS,
optional DVI
PCI slot,
Mini-PCI and PCI Express Mini card socket, 8-bit GPIO
Onboard 6 x Intel® Gigabit LAN, HD Audio, 6 x COM, USB 2.0
DC 9V ~ 24V full range input or
standard 20-pin ATX P/S
|
|
|
|
|
|
|
LS-572
|
|
|
Intel® Core™ 2 Quad with 2 x DVI or LVDS 5.25" SBC
|
|
|
|
|
Intel®
CoreTM
2 Quad /
CoreTM
2 Duo Desktop, 800/1066/1333 MHz FSB
Intel® Q35 & ICH9DO, DDRII 667/800 MHz up to
4GB
Onboard VGA, Dual DVI or LVDS interface
1 x PCI slot & 1 x Mini-PCI
socket
Onboard 2 x Intel®
Gigabit LAN, HD Audio, LPT, SMBus
1 x RS-232/422/485 & 5 x RS232, 8 x USB 2.0, IrDA, GPIO
|
|
|
|
|
|
|
LS-571
|
|
|
Intel® Core™ 2 Duo 5.25" Motherboard
|
|
|
|
|
Intel® CoreTM 2
Duo (Merom) processor @ 800MHz FSB
Intel® GME965 &
ICH8M, DDRII 533 / 667MHz up to 2GB,
Optional onboard 1GB DDRII SDRAM
Onboard VGA,
TV-out, DVI, 18/24-bit Dual Channel LVDS
2 x
Mini-PCI and 1 x PCI, 2 x Intel® Gigabit LAN, RS232/422/485, HD
Audio,
SMBus,
USB 2.0, 8-bit GPIO, LPT, FDD, IrDA, CompactFlash,
DC
12V input or standard 20-pin ATX power supply
|
|
|
|
|
|
|
LS-570
|
|
|
Intel® Core Duo / Core Solo Miniboard with 4 Gigabit Ethernet
|
|
|
|
|
5.25" Intel® CoreTM 2 Duo / CoreTM Duo solution Miniboard
Intel® CoreTM Duo / CoreTM Solo / Celeron M processor @ 533/667 MHz FSB
Intel® 945GME & ICH7M, 2 x 240-pin DDRII 533/667 MHz support up to 3GB
Onboard VGA, LVDS, DVI
Onboard 4 x Intel® Gigabit Ethernet controller
2 x SATA, 4 x COM, 6 x USB 2.0, LPT, GPIO,
Onboard CompactFlash & Mini-PCI socket
Standard ATX power supply / Full range 8 ~ 24V DC input
|
|
|
|
|
|
|
BackToTop |
|
|
Industrial 3.5" Embedded Miniboard
|
|
|
|
NEW |
|
|
|
|
LE-37T |
|
|
3.5 Inches with Intel®
Atom™
Amston
Lake Processor
X Series |
 |
|
|
3.5" Miniboard with Intel® Atom™ Amstion Lake Processor X Series support for one DDR5
SO-DIMM up to 4800 MHz 32GB. HDMI, LVDS, DisplayPort++, HD audio, 2 x Intel® 2.5 Gigabit
LAN, 1 x SATA3, 2 x USB3.2 Gen2, 2 x USB2.0, 1 x Type-C (DP Alt. Mode), 4 x RS232, 2 x
RS232/422/485, 8-bit GPIO, 1 x M.2 (Key E 2230) for Wi-Fi and Bluetooth, 2 x M.2
(Key M 2280) support Gen3 PCIe x2 for NVMe, DC input 9V ~ 35V
|
|
NEW |
|
|
|
|
LE-37S |
|
|
3.5 Inches with Intel®
Core™
Ultra
Meteor Lake series Processors |
 |
|
|
3.5" Miniboard with Intel® Core™ Ultra Meteor Lake Ultra series processors support for two DDR5
SO-DIMM up to 5600 MHz 96GB. HDMI, LVDS, DisplayPort++, HD audio, 3 x Intel® 2.5 Gigabit
LAN, 2 x SATA3, 3 x USB3.2 Gen2, 2 x USB2.0, 1 x Type-C (DP Alt. Mode), 2 x RS232, 2 x
RS232/422/485, 8-bit GPIO, 1 x Mini-PCIe socket, 1 x M.2 (Key E 2230) for Wi-Fi and
Bluetooth, 2 x M.2 (Key M 2280) support PCIe Gen4 for NVMe, DC input 9V ~ 35V
|
|
|
|
|
|
|
LE-37R |
|
|
3.5 Inches with Intel® 12th
& 13th Gen P/U Processor |
 |
|
|
3.5" Miniboard with Intel® 12th & 13th Gen P/U Processors support for two DDR5 SO-DIMM
up to 4800 MHz 64GB. HDMI, LVDS, DisplayPort, HD audio, 1 x Intel® Gigabit PHY LAN,
2 x Intel® 2.5 Gigabit LAN, 2 x SATA3, 3 x USB3.2 Gen2, 1 x Type-C (DP Alt. Mode),
2 x USB2.0, 2 x RS232/422/485, 2 x RS232, 8-bit GPIO, 1 x Mini-PCIe socket, 1 x M.2
(Key E 2230) for Wi-Fi and Bluetooth, 2 x M.2 (Key M 2280) support PCIe Gen4 for NVMe,
|
|
|
|
|
|
|
LE-37P
|
|
|
3.5 Inches with Intel®
Tiger Lake
/11th Gen H Processor |
 |
|
|
3.5" Miniboard with Intel® Tiger Lake /11th Gen H Processors support for one DDR4 SO-DIMM
3200 MHz up to 32GB. HDMI, LVDS, DisplayPort, HD audio, 1 x Intel® Gigabit PHY LAN,
1 x Intel® 2.5 Gigabit LAN, 2 x SATA3, 6 x USB3.2 Gen2, 1 x USB3.2 Gen2 (Type E),
2 x USB2.0, 2 x RS232/422/485, 2 x RS232, 8-bit GPIO, 1 x Mini-PCIe socket, 1 x M.2
(Key E 2230) for Wi-Fi and Bluetooth, 2 x M.2 (Key M 2280) support PCIe Gen4 for NVMe,
|
|
|
|
|
|
|
LE-37O
|
|
|
3.5 Inches with Intel®
Tiger Lake
UP3 Processor |
 |
|
|
3.5" Miniboard with Intel® Tiger Lake UP3 Processors support for one DDR4 SO-DIMM 3200
MHz up to 32GB. HDMI, LVDS, DisplayPort, VGA, HD audio, 2 x Gigabit ethernet,
2 x SATA3, 4 x USB3.2 Gen2, 2 x USB2.0, 2 x RS232/422/485, 2 x RS232, 8-bit GPIO,
1 x Mini-PCIe socket, 1 x M.2 (Key E 2230) for Wi-Fi and Bluetooth, 1 x M.2 (Key M 2280)
support PCIe Gen4 for NVMe, DC input 9V ~ 35V input
|
|
|
|
|
|
|
LE-37N
|
|
|
3.5 Inches with Intel®
Whiskey Lake
U Processor |
 |
|
|
3.5" Miniboard with Intel® Whiskey Lake U Processors support for two DDR4
SO-DIMM 2400 MHz up to 64GB. HDMI, LVDS, DisplayPort, HD audio,
2 x Gigabit ethernet, 2 x SATA3, 4 x USB3.1 Gen2, 4 x USB2.0, 2 x RS232/422/485,
2 x RS232, 8-bit GPIO, 1 x Mini-PCIe socket, 1 x M.2 (Key E), DC input 9V ~ 35V input
|
|
|
|
|
|
|
LE-37M
|
|
|
3.5 Inches with 8th
& 9th
Gen Intel®
Core™
H-series Processor |
 |
|
|
3.5" Miniboard with 8th & 9th Gen Intel® Core™ H-series Processors support for DDR4
SO-DIMM 2666 MHz up to 64GB. HDMI, LVDS, DisplayPort, VGA, HD audio,
2 x Gigabit ethernet, 2 x SATA3, 4 x USB3.1 Gen2, 4 x USB2.0, 2 x RS232/422/485,
2 x RS232, 8-bit GPIO, 1 x Mini-PCIe socket, DC input 9V ~ 35V input
|
|
|
|
|
|
|
LS-37L
|
|
|
3.5 Inches
with Intel® 8th
& 9th Desktop Processor |
 |
|
|
3.5" Miniboard Intel® Core™ Desktop Processors support for DDR4 SO-DIMM 2666 MHz
up to 32GB. HDMI, LVDS, DisplayPort, DVI, VGA, HD audio, 2 x Gigabit ethernet, 2 x
SATA3, 4 x USB3.1 Gen2, 4 x USB2.0, 4 x RS232, 2 x RS232/422/485, 8-bit GPIO, 1 x
Mini-PCIe socket, DC input 9V ~ 25V input
|
|
|
|
|
|
|
LS-37K
|
|
|
3.5 Inches
Embedded with Intel® Skylake / Kaby
Lake(6th/7th)
S-Series
and Xeon® E3-1200 v5
Desktop Processor |
|
 |
|
|
3.5" Miniboard embedded Intel® Skylake / Kaby Lake Core™ S-Series and Xeon®
E3-1200 v5 Processors, support for DDR4 SO-DIMM 1866/2133 MHz up to 16GB. HDMI,
LVDS, DisplayPort, DVI, VGA, HD audio, 1 x Gigabit ethernet, 1 x Gigabit PHY ethernet,
2 x SATA3, 4 x USB3.0, 4 x USB2.0, 5 x RS232, 1 x RS232/422/485, 8-bit GPIO, 1 x
Mini-PCIe socket, 1 x LPC, DC input 9V ~ 35V input
|
|
|
|
|
|
|
LE-37I
|
|
|
3.5 Inches
Embedded with Intel® Skylake / Kaby Lake(6th/7th) H-Series
and Xeon® E3-1505L v6 Mobile Processor |
|
 |
|
|
3.5" Miniboard embedded Intel® Skylake / Kaby Lake Core™ H-Series and Xeon®
E3-1505L v6 Processors, support for DDR4 SO-DIMM 2133 MHz up to 16GB. HDMI,
LVDS, DisplayPort, DVI, VGA, HD audio, 1 x Gigabit ethernet, 1 x Gigabit PHY ethernet,
2 x SATA3, 4 x USB3.0, 4 x USB2.0, 5 x RS232, 1 x RS232/422/485, 8-bit GPIO,
2 x Mini-PCIe sockets, 1 x SIM slot, 1 x LPC, full ranged DC 9V ~ 30V input
|
|
|
|
|
|
|
LE-37H
|
|
|
3.5 Inches
Embedded with Intel® Apollo Lake Series Mobile Processor |
|
 |
|
|
3.5" Miniboard embedded Intel® Apollo Lake Series processors,
Support for DDR3L SO-DIMM 1866 MHz up to 8GB. HDMI, LVDS, DisplayPort, HD
audio, 2 x Gigabit ethernet, 2 x SATA3, 4 x USB3.0, 2 x USB2.0, 5 x RS232, 1 x
RS232/422/485, 8-bit GPIO, 2 x Mini-PCIe sockets, 1 x SIM slot, 1 x LPC,
|
|
|
|
|
|
|
LE-37G
|
|
|
3.5 Inches
Embedded with Intel® Skylake / Kaby
Lake (6th/7th) U-Series Mobile Processor |
|
 |
|
|
3.5" Miniboard embedded Intel® Skylake / Kaby Lake (6th/7th) Core™ U-Series processors,
Support for DDR4 SO-DIMM 1866/2133 MHz up to 16GB. HDMI, LVDS, DisplayPort or VGA,
HD audio, 1 x Gigabit ethernet, 1 x Gigabit PHY ethernet, 2 x SATA3, 4 x USB3.0, 4 x
USB2.0, 5 x RS232, 1 x RS232/422/485, 8-bit GPIO, 2 x Mini-PCIe sockets, 1 x SIM slot,
1 x LPC, DC 9V ~ 30V input
|
|
|
|
|
|
|
LE-37F
|
|
|
3.5 Inches
Embedded with Intel® Braswell Series Mobile Processor |
|
 |
|
|
3.5" Miniboard embedded Intel® Braswell Series processors,
Support for DDR3L SO-DIMM 1600 MHz up to 8GB. Optional DisplayPort,
HDMI, LVDS, HD audio, 2 x Gigabit ethernet, 2 x SATA3, 4 x USB3.0,
2 x USB2.0, 1 x RS232/422/485, 5 x RS232, 8-bit GPIO, 2 x Mini-PCIe sockets,
1 x SIM slot, 1 x LPC, DC 6V ~ 30V input
|
|
|
|
|
|
|
LE-37E |
|
|
3.5 Inches
Embedded with Intel® Broadwell (5th) Haswell (4th) Core™ U-series Mobile Processor
|
|
 |
|
|
3.5" Miniboard embedded Intel® Broadwell(5th)/Haswell(4th) Core™ Mobile U-series processors,
Support for DDR3L SO-DIMM 1333/1600 MHz up to 8GB. Onboard DisplayPort,
HDMI, DVI, LVDS, HD audio, 1 or 2 Gigabit ethernet, 2 x SATA3, 2 x USB3.0,
4 x USB2.0, 1 x RS232/422/485, 5 x RS232, 8-bit GPIO, 2 x Mini-PCIe sockets,
1 x SIM slot, 1 x LPC, DC 9V ~ 30V input
|
|
|
|
|
|
|
|
|
|
|
LE-37D |
|
|
3.5 Inches
Embedded Mini board Intel® Celeron® J1900,N2930 &
Atom® E3845 Processor
|
|
 |
|
|
3.5" SBC embedded Intel® Celeron™ J1900 / N2930 & Atom™ E3845 Mobile processor,
Support for DDR3L SO-DIMM 1066/1333 MHz up to 8GB. Onboard DisplayPort,
HDMI, VGA, 2 x LVDS, HD audio, 2 x Gigabit ethernet, 1 x SATAII, 1 x USB3.0,
5 x USB2.0, 1 x RS232/422/485, 5 x RS232, 8-bit GPIO, 2 x Mini-PCIe sockets,
1 x SIM slot, 1 x CFast, Full range DC 6V ~ 30V input
|
|
|
|
LE-37C |
|
|
Support
4th/5th Generation Intel® Core™ i7 / i5 / i3 and Celeron
® (Haswell / Broadwell) BGA1364 CPU
|
|
 |
|
|
3.5" SBC support 4th/5th generation Intel® Core™ i7 / i5 / i3 & Celeron® Mobile processor,
Mobile Intel® QM87 Express chipset, DDR3L 1333/1600 MHz up to 8GB,
Onboard VGA, LVDS, DVI, DisplayPort, HD audio, 1 x Gigabit ethernet, 2 x SATAIII,
1 x RS232/422/485, 1 x RS232, 2 x USB2.0, 4 x USB3.0, 8-bit GPIO, 1 x IrDA,
2 x Mini-PCIe sockets, 1 x SIM slot, 1 x CFast, Full range DC 9V ~ 24V input
|
|
|
|
LS-37B
|
|
|
Support
3rd Generation Intel® Core™ i7 / i5 / i3 Mobile processor
|
|
|
|
|
3.5" SBC support 3rd generation Intel® Core™ i7 / i5 / i3 Mobile processor,
Mobile Intel® QM77 Express chipset, DDR3 1066/1333/1600 MHz up to 8GB,
Onboard VGA, LVDS, DVI, HD audio, 1 x Gigabit ethernet, 2 x SATA,
1 x RS232/422/485, 1 x RS232, 2 x USB2.0, 4 x USB3.0, 8-bit GPIO,
2 x Mini-PCIe sockets, 1 x SIM slot, Full range DC 9V ~ 24V input
|
|
|
|
LE-37A
|
|
|
3.5 Inches Embedded Mini board Intel® Celeron® Processor 807UE or 827E or 847E
|
|
|
|
|
3.5" SBC supports Intel®
Sandy
Bridge
Processor 807UE/827E/847E,
Intel®
HM65 Express chipset,
DDR3 1066/1333 MHz up to 4GB (LE-37ANB),
or 8GB (LE-37AC6
/ LE-37ABU), Support
CRT, DVI, LVDS,
Gigabit LAN, USB2.0,
HD
Audio,
Serial ATAIII, PCIE mini card, LPC, mSATA, Full
ranged 9V~24V(±5%)
DC Input
|
|
|
|
LE-380
|
|
|
3.5"
SBC with onboard AMD Dual-core T56N 1.65 GHz
|
|
|
|
|
Onboard AMD
Dual-core T56N 1.65 GHz
AMD A55E FCH
chipset, DDR3 1066/1333 MHz up to 4GB,
Support
VGA, LVDS, DVI, HD audio, Intel®
Giga LAN, 2 x SATA, CFast socket
1 x RS232/422/485, 5 x RS232,
6 x USB2.0, LPT, 8-bit GPIO, SMBus
Mini-PCIe
& Mini-PCI sockets, Full range DC 5V ~ 24V input
|
|
|
|
LE-379
|
|
|
3.5"
SBC with onboard
Intel® Atom™ Processor N2800 or D2550
|
|
|
|
|
3.5" SBC supports Intel® Atom™
processor D2550 or N2800
Intel® NM10 Express chipset,
DDR3-800/1066 SO-DIMM
up to 4GB
Onboard VGA, DVI , LVDS, 1 x Intel® Giga
LAN, HD Audio, 2 x SATA
PCIe mini card
& Mini-PCI sockets, 1 x LPT
6 x COM, 6 x USB2.0, DC 5V ~ 24V input
|
|
|
|
|
|
|
LS-378
|
|
|
Support
2nd Generation Intel® Core™ i7 / i5 / i3 Mobile processor
|
|
|
|
|
3.5"
SBC support 2nd generation Intel®
Core™ i7 / i5 / i3 Mobile processor
Mobile Intel®
QM67 Express chipset, DDR3 1066/1333 MHz up to 8GB,
Onboard VGA,
LVDS, DVI, HD audio, 1 x Gigabit ethernet, 2 x SATAIII
1 x RS232/422/485, 1 x RS232,
6 x USB2.0, 8-bit GPIO, SIM socket
2
x Mini-PCIe sockets, Full range DC 9V ~ 24V input
|
|
|
|
LS-377
|
|
|
3.5"
SBC support Intel® Core™ i7 / i5 / i3 Mobile processor
|
|
|
|
|
Intel®
Core™ i7 / i5 / i3 Mobile processor ( Dual Core )
Mobile Intel®
QM57 Express chipset, DDR3 800/1066 MHz up to 4GB,
Support VGA,
LVDS, DVI, HD audio, Intel®
Giga LAN, 2 x SATA with RAID 0/1
1 x RS232/422/485, 1 x RS232,
6 x USB2.0, 8-bit GPIO, SMBus
Mini-PCIe
& Mini-PCI sockets, Full range DC 9V ~ 24V input
|
|
|
|
LE-376
|
|
|
3.5"
embedded board for Intel® Atom™ dual-core solution
|
|
|
|
|
Onboard
Intel® Atom™ D525/D510 dual-core or D410/N450 single-core processor
Intel® ICH8M system
chipset
DDR2-667 SO-DIMM
SDRAM up to 2GB or 4GB
Onboard VGA, LVDS, 3
x Intel® Giga LAN, HD Audio 6
x COM, 5 x USB2.0, 2 x SATA, 1 x LPT, 1 x SMBus 1
x PCIE mini card socket & 1 x Mini-PCI socket DC
9V ~ 24V input
|
|
|
|
|
|
|
LE-375
|
|
|
Fanless
3.5"
embedded board for Intel® Atom™ solution
|
|
|
|
|
Intel® Atom™
Z510P 1.1GHz processor @ 400MHz FSB
Intel®
SCH US15WP, DDR2 up to 2GB, VGA, DVI, LVDS
Intel®
Giga LAN, IDE, USB2.0, COM, HD audio
CompactFlash
card, SD card, and PCIe mini card socket
Full
range 9~24V DC input
|
|
|
|
LE-374
|
|
|
Fanless
3.5"
embedded board for Intel® Atom™ solution
|
|
|
|
|
Intel® Atom™ N270 processor @ 533 MHz FSB
Intel®
945GSE & ICH7M chipset
DDR2 up
to 2GB, DVI, LVDS and HDTV
Intel®
Giga LAN, SATA, USB2.0, COM
CompactFlash
and Mini-PCI socket, Audio
DC 9V ~
24V inputs
|
|
|
|
LS-373
|
|
|
3.5" Intel® Core 2
Duo (Penryn) based on GM45 chipset
|
|
|
|
|
Intel® CoreTM 2 Duo
processor with socket-P @ 667/800/1066 MHz FSB
Intel® GM45
& ICH9M, DDR3 800/1066 MHz up to 4GB
Onboard VGA, HDTV, 24-bit Dual
Channel LVDS
Mini-PCI
and PCI Express Mini card socket. 8-bit GPIO
Onboard 2 x Intel® Gigabit LAN,
HD Audio, SPDIF
RS232/422/485, USB 2.0, DC
12V input
|
|
|
|
|
|
|
LS-372
|
|
|
3.5" Intel® Core 2
Duo (Merom) @ 800 MHz FSB
|
|
|
|
|
Intel® CoreTM
2
Duo (Merom)
processor @ 800 MHz FSB
Intel® GME965 and
ICH8M chipset
DDRII
SO-DIMM up to 2GB, Onboard VGA, TV-out / DVI
24-bit Dual
Channel LVDS, 1 x SATAII, 1 x
Mini-PCI socket
Onboard 1 x Intel® Gigabit LAN,
HD Audio, SPDIF, RS232
USB 2.0, 8-bit GPIO, CompactFlash
socket,
DC12V input
|
|
|
|
LS-371
|
|
|
3.5" Intel® Core 2
Duo / Core Duo / Core Solo Miniboard
|
|
|
|
|
Intel® CoreTM
2
Duo / CoreTM
Duo / CoreTM Solo processor , 533 / 667 MHz FSB
Intel® 945GME and
ICH7M chipset
DDRII
SO-DIMM up to 2GB, Onboard VGA, DVI
18-bit Dual
Channel LVDS, 2 x SATA
1 x
Mini-PCI, Onboard 1 x Intel® Gigabit LAN,
5.1 channel Audio
RS232/422/485, USB 2.0, 8-bit GPIO,
IrDA, CompactFlash socket
8 V ~ 24 V Full range DC input
|
|
|
|
|
|
|
|
|
|
|
|
LE-370CM6
|
|
|
3.5"
Fanless Embedded Celeron M 600MHz processor Miniboard
|
|
|
|
|
3.5" Fanless
Embedded Intel® ULV Celeron M Miniboard
Embedded Intel® ULV Celeron
M 600Mhz processor with 400MHz FSB
Intel® 852GM & ICH4
Chipset. 1 x DDR 200/266 SDRAM up to 1GB
Onboard VGA,
24-bit Dual-channel LVDS Interface.
IDE1 support DOM with
+5V power supply.
Onboard 5-pin LCD
inverter connector and CompactFlash socket.
One Intel® 10/100Mbps
LAN, 2 x USB, RS232 and IrDA ports
Mini-PCI and Audio
Interface.
|
|
|
|
LE-370
|
|
|
3.5"
Intel® Pentium M / Celeron M process Miniboard
|
|
|
|
3.5" Embedded
Intel® Pentium M / Celeron M Miniboard
Intel® Pentium M /
Celeron M processor with 400/533MHz FSB
Intel® 852GME & ICH4
Chipset. 1 x DDR 266/333 SDRAM up to 1GB
Onboard VGA,
24-bit dual channel LVDS Interface.
IDE1 support DOM with
+5V power supply.
Onboard 5-pin LCD
inverter connector and CompactFlash socket.
One Intel® 10/100Mbps
LAN, 2 x USB, RS232 and IrDA ports
Mini-PCI and Audio
Interface.
|
|
BackToTop |
Mini-ITX / Nano-ITX Embedded Motherboard
|
|
NEW |
|
|
LV-6717
|
Mini-ITX Desktop with
Intel®
Core™
Ultra Arrow Lake-S
Processor |
|
|
Mini-ITX Desktop with Intel® Core™ Ultra Arrow Lake-S processor,
Support for two DDR5 UDIMM sockets up to 128GB,
2 x DisplayPort, 2 x HDMI, 1 x LVDS, HD Audio, 2 x SATA3, 1 x 8-bit GPIO,
1 x Intel® I226-LM 2.5 Gigabit LAN, 1 x Intel® I226-V 2.5 Gigabit LAN,
2 x RS232/422/485, 2 x RS232, 2 x USB2.0, 6 x USB3.2 Gen2,
1 x PCI-Express X16 slot, 1 x M.2 (Key E), 2 x M.2 (Key M).
|
|
NEW |
|
|
LV-6716
|
Mini-ITX Mobile with
Intel®
Core™
Ultra
Meteor Lake series
Processors |
|
|
Mini-ITX Mobile with Intel® Core™ Ultra Meteor Lake series processors,
Support for two DDR5 SO-DIMM 5600 MHz up to 96GB,
1 x DisplayPort ++, 2 x HDMI, 1 x LVDS, HD Audio , 2 x SATA3, 1 x 8-bit GPIO,
1 x Intel® I226-LM 2.5 Gigabit LAN, 2 x Intel® I226-V 2.5 Gigabit LAN,
2 x RS232/422/485, 4 x RS232, 4 x USB2.0, 4 x USB3.2 Gen2, 1 x SIM,
1 x PCI-Express X16 slot, 1 x Mini-PCIe, 1 x M.2 (Key E), 2 x M.2 (Key M).
|
|
|
|
|
LV-6715
|
Mini-ITX Mobile with
Intel® 12th & 13th Gen H
Processor |
|
|
Mini-ITX Mobile with Intel® 12th & 13th Gen H processor,
Support for two DDR5 SO-DIMM 4800 MHz up to 64GB,
2 x DisplayPort, 2 x HDMI, 1 x LVDS, HD Audio, 2 x SATA3, 1 x 8-bit GPIO,
1 x Intel® Gigabit PHY LAN, 2 x Intel® 2.5 Gigabit LAN,
2 x RS232/422/485, 4 x RS232, 4 x USB2.0, 4 x USB3.2 Gen2, 1 x SIM,
1 x PCI-Express X16 slot, 1 x Mini-PCIe, 1 x M.2 (Key E), 2 x M.2 (Key M).
|
|
|
|
|
LV-6714
|
Mini-ITX Desktop with
Intel® 12th & 13th & 14th Gen
Processor |
|
|
Mini-ITX Desktop with Intel® 12th & 13th & 14th Gen processor,
Support for two DDR5 DIMM 4800 MHz up to 64GB,
2 x DisplayPort, 2 x HDMI, 1 x LVDS, HD Audio, 3 x SATA3, 1 x 8-bit GPIO,
1 x Intel® Gigabit PHY LAN, 1 x Intel® 2.5 Gigabit LAN,
2 x RS232/422/485, 4 x RS232, 2 x USB2.0, 6 x USB3.2 Gen2, 1 x SIM,
1 x PCI-Express X16 slot, 1 x M.2 (Key E), 1 x M.2 (Key M), 1 x M.2 (Key B).
|
|
|
|
LV-6713
|
Mini-ITX Mobile with
Intel® Tiger Lake /11th Gen H Processor |
|
.png)
|
Mini-ITX Mobile with Intel® Tiger Lake / 11th Gen H processor,
Support for two DDR4 SO-DIMM 3200 MHz up to 64GB,
2 x DisplayPort, 2 x HDMI, 1 x LVDS, HD Audio, 3 x SATA3, 1 x 8-bit GPIO,
1 x Intel® Gigabit PHY LAN, 1 x Intel® 2.5 Gigabit LAN,
2 x RS232/422/485, 4 x RS232, 2 x USB2.0, 6 x USB3.2 Gen2,
1 x PCI-Express X16 slot, 1 x Mini-PCIe, 1 x M.2 (Key E), 1 x M.2 (Key M).
|
|
|
|
|
LV-6712
|
Mini-ITX Mobile with
Intel® Tiger UP3 Processor |
|
|
Mini-ITX Mobile with Intel® Tiger UP3 processor,
Support for two DDR4 SO-DIMM 3200 MHz up to 64GB,
2 x DisplayPort, 2 x HDMI, 1 x LVDS, HD Audio, 2 x SATA3, 1 x 8-bit GPIO,
1 x Intel® Gigabit PHY LAN, 1 x Intel® Gigabit LAN,
2 x RS232/422/485, 4 x RS232, 4 x USB2.0, 4 x USB3.2 Gen2,
1 x PCI-Express X1 slot, 2 x Mini-PCIe, 1 x M.2 (Key M).
|
|
|
|
|
LV-67Z
|
Mini-ITX Mobile with
Intel® Whiskey U Processor |
|
|
Mini-ITX Mobile with Intel® Whiskey U processor,
Support for two DDR4 SO-DIMM 2400 MHz up to 64GB,
DisplayPort, HDMI, LVDS, HD Audio, 2 x SATA3, 8-bit GPIO,
1 x Intel® Gigabit PHY LAN, 1 x Intel® Gigabit LAN,
2 x RS232/422/485, 4 x RS232, 4 x USB2.0, 4 x USB3.1 Gen2,
1 x PCI-Express X4 slot, 1 x Mini-PCIe, 1 x M.2 (Key E).
|
|
|
|
|
LV-67X
|
Mini-ITX Desktop
8th
& 9th Generation
Intel® Core™
Processor |
|
|
Mini-ITX desktop 8th & 9th Generation Intel® Core™ processor,
Support for two DDR4 DIMM 2666 MHz to 64GB.
Integrated VGA, DisplayPort, DVI, HDMI, LVDS, HD Audio,
1 x Intel® Gigabit PHY LAN, 1 x Intel® Gigabit LAN, 3 x SATA3,
2 x RS232/422/485, 4 x RS232, 4 x USB2.0, 6 x USB3.1 Gen2, 8-bit GPIO,
1 x PCI-Express X16 slot, 1 x Mini-PCIe, 1 x Half-Size Mini-PCIe, 1 x SIM.
|
|
|
|
|
LV-67W
|
Mini-ITX Mobile
8th
& 9th Generation
Intel® Core™
Processor |
|
|
Mini-ITX moblie 8th & 9th Generation Intel® Core™ H*-series processor,
Support for two DDR4 SO-DIMM 2666 MHz to 64GB.
Integrated VGA, DisplayPort, DVI, HDMI, LVDS, HD Audio,
1 x Intel® Gigabit PHY LAN, 1 x Intel® Gigabit LAN, 3 x SATA3,
1 x RS232/422/485, 5 x RS232, 4 x USB2.0, 6 x USB3.1 Gen2, 2 x 8-bit GPIO,
1 x PCI-Express X16 slot, 2 x Mini-PCIe ,1 x SIM.
|
|
|
|
|
LV-67U
|
Mini-ITX Mobile
Intel® Apollo Lake Series Mobile Processor |
|
|
Mini-ITX mobile Intel® Apollo Lake Series processor,
Support for two DDR3L SO-DIMM 1866 MHz to 8GB.
Onboard DisplayPort or DVI, HDMI, LVDS, HD Audio,
2 x Intel® Gigabit LAN, 2 x SATA3, 4 x RS232,
2 x optional RS232/422/485, 4 x USB2.0, 4 x USB3.0, 8-bit GPIO, 1 x PCI slot,
1 x MiniPCI, 1 x Mini-PCIe , 1 x SIM, 1 x SD card.
|
|
|
|
|
LV-67T
|
Mini-ITX Mobile
Intel® Skylake / Kaby Lake Intel®
6th / 7th Core™ U-series Processor |
|
|
Mini-ITX mobile Intel® Skylake / Kaby Lake Intel® 6th / 7th Core™ U-series Processor,
Support for two DDR4 SO-DIMM 1866/2133 MHz to 32GB.
Onboard DVI-I, LVDS, Displayport/VGA, HD Audio,
1 x Intel® Gigabit PHY LAN,1 x Intel® Gigabit LAN, SATA3, 5 x RS232,
1 x RS232/422/485, 4 x USB2.0, 4 x USB3.0, 8-bit GPIO, 1 x PCI slot,
1 x MiniPCI, 2 x Mini-PCIe, 1 x SIM.
|
|
|
|
|
LV-67S
|
Mini-ITX Desktop
Skylake / Kaby Lake Intel® 6th / 7th Gen Core™ S-series
and Xeon® E3-1200 v5
/ v6 Processor LGA1151 CPU |
|
|
Mini-ITX desktop Skylake / Kaby Lake Intel® 6th / 7th Core™ S-series and Xeon® E3-1200 v5 / v6
Processor, FCLG1151 package. Support for two DDR4 DIMM 1866 / 2133 MHz to 32GB.
Onboard DisplayPort, DVI, HDMI, VGA, LVDS, HD Audio, 5 x RS232, 1 x RS232/422/485,
1 x Intel® Gigabit PHY LAN,1 x Intel® Gigabit LAN, SATA3, 4 x USB2.0, 6 x USB3.0, 8-bit GPIO,
PCI-Express X16 slot, 1 x Mini-PCIe, 1 x Half-Size Mini-PCIe, 1 x SIM.
|
|
|
|
|
LV-67R
|
Mini-ITX
Mobile
Intel® Skylake / Kaby Lake (6th / 7th) Gen Core™ H-series and Xeon® E3-1505M
v6 Processor |
|
|
Mini-ITX mobile Intel® Skylake / Kaby Lake (6th / 7th) Gen Core™ H-series and Xeon® E3-1505M
v6 Processor, Support for two DDR4 SO-DIMM 2133 MHz to 32GB.
Onboard DisplayPort, DVI-I, HDMI, VGA, LVDS, HD Audio, SATA3, 4 x USB2.0, 6 x USB3.0,
1 x Intel® Gigabit PHY LAN,1 x Intel® Gigabit LAN, 5 x RS232, 1 x RS232/422/485, 8-bit GPIO,
PCI-Express X16 slot, 1 x Mini-PCIe, 1 x Half-Size Mini-PCIe, 1 x SIM.
|
|
|
|
|
LV-67P
|
Mini-ITX
Mobile
Intel® Braswell Series Processor |
|
|
Mini-ITX mobile Intel® Braswell Series Processor,
Support for two DDR3L SO-DIMM MHz to 8GB.
Onboard DVI, HDMI, optional VGA / LVDS / DisplayPort, HD Audio,
2 x Intel® Gigabit LAN, SATA3, 5 x RS232, 1 x RS232/422/485, 4 x USB2.0,
4 x USB3.0, 8-bit GPIO, PCI-Express X16 slot, 1 x Mini-PCIe , 1 x mSATA.
(PCIe X16 slot only support 1 Lane)
|
|
|
|
|
LV-67O
|
Mini-ITX Embedded Intel® Celeron® J1900 , N2930 &
Atom® E3845 Processor |
|
 |
Mini-ITX embedded Intel® Celeron™ J1900 / N2930
& Atom™ E3845 Mobile processor.
Support for two DDR3L SO-DIMM 1066/1333 MHz up to 8GB.
Onboard DisplayPort, DVI, VGA, 2 x LVDS, HD Audio, SATAII
2 x Intel® Gigabit LAN, 5 x RS232, 1 x RS232/422/485,
5 x USB2.0, 1 x USB3.0, 8-bit GPIO, PCI-Express X16 slot, 1 x Mini-PCIe.
|
|
|
|
LV-67N
|
Support
4th Generation Intel®Core™ i7 / i5 / i3 LGA1150 CPU
|
|
 |
Mini-ITX support 4th generation Intel® Core™ i7 / i5 / i3 LGA 1150 processor,
Intel® Q87 Express chipset, DDR3/DDR3L 1333/1600 MHz DIMM up to 16GB,
Onboard VGA, DVI, LVDS, DisplayPort, HD Audio, 2 x Intel® Gigabit LAN,
4 x SATA with RAID, 1 x RS232/422/485, 3 x RS232, 4 x USB2.0,
6 x USB3.0, 8-bit GPIO, PCI-Express X16 slot, 2 x Mini-PCIe .
|
|
|
|
|
|
|
LV-67M |
Support
4th/5th Generation Intel®Core™ i7 / i5 / i3 & Celeron® (Haswell / Broadwell) BGA1364 CPU |
|
|
Mini-ITX support 4th/5th generation Intel® Core™ i7 / i5 / i3
& Celeron® Mobile Processor.
Package type: FCBGA1364Intel® QM87 Express chipset,
DDR3L SO-DIMM 1333/1600 MHz up to 16GB,
Onboard VGA, DVI, LVDS, DisplayPort, HD Audio, 2 x Intel® Gigabit LAN,
4 x SATA with RAID, 1 x RS232/422/485, 5 x RS232, 4 x USB2.0,
6 x USB3.0, 8-bit GPIO, PCI-Express X16 slot, 2 x Mini-PCIe .
|
|
|
|
LV-683 |
Onboard AMD
Dual-core T56N 1.65 GHz
|
|
|
Onboard AMD
Dual-core T56N 1.65 GHz
AMD A55E FCH chipset, DDR3
1066/1333 MHz up to 8GB,
Support VGA,
LVDS, DVI, HD audio, 2 x Intel®
Giga LAN, 4 x SATA, 1 x SIM
1 x RS232/422/485, 5 x RS232,
10 x USB2.0, LPT, 8-bit GPIO, SMBus
PCI slot, Mini-PCIe &
Mini-PCI sockets, ATX P/S or Full range DC 5V ~ 24V input
|
|
|
|
LV-67L
|
Mini-ITX
Embedded Intel® Celeron® Processor 807UE or 847E
|
|
|
Mini-ITX
supports Intel®
Sandy
Bridge
Processor 807UE/847E,
Intel®
HM65 Express chipset, DDR3 1066/1333 MHz up to 4GB (LV-67LNB),
or 16GB (LV-67LBU), Support
CRT, DVI, LVDS, 2
x Gigabit LAN, 10 x USB2.0,
HD
Audio, PCI-Express X16, Serial
ATAII, Serial ATAIII, PCIE mini card, LPC, mSATA, Standard 24-pin ATX P/S or
Full
ranged 9V~24V(±5%)
DC Input
|
|
|
|
LV-67K
|
Support
3rd Generation Intel®Core™ i7 / i5 / i3 Mobile processor
|
|
|
Mini-ITX support
3rd generation Intel® Core™ i7 / i5 / i3 Mobile processor.
Mobile Intel® QM77 Express chipset, DDR3 1066/1333/1600 MHz up to 16GB,
Onboard VGA, LVDS, DVI, HD audio, 2 x Gigabit ethernet, 6 x SATA
1 x RS232/422/485, 5 x RS232, 6 x USB2.0, 4 x USB3.0, SPDIF,
8-bit GPIO,
PCI-Express X16 slot, 2 x Mini-PCIe sockets, 1 x SIM socket
Standard 24-pin ATX P/S or Full range DC 9V ~ 24V input.
|
|
|
|
LV-67J
|
Support
3rd Generation Intel®Core™ i7 / i5 / i3 LGA1155 CPU
|
|
|
Mini-ITX support
3rd generation Intel® Core™ i7 / i5 / i3 LGA 1155 processor.
Intel® Q77 Express chipset, DDR3 1066/1333 MHz up to 16GB,
Onboard VGA, DVI, HD Audio, 2 x Intel® Gigabit LAN, 4 x SATA with RAID,
1 x RS232/422/485, 3 x RS232, 4 x USB2.0, 4 x USB3.0, 8-bit GPIO,
PCI-Express X16 slot, Mini-PCIe & Mini-PCI socket
|
|
|
|
LV-67I |
Onboard
Intel® Atom™ Processor N2800 or D2550 |
|
|
Mini-ITX supports Intel® Atom™
processor D2550 or N2800
Intel® NM10 Express chipset
DDR3-800/1066 SO-DIMM
up to 4GB
Onboard VGA, DVI, LVDS, 2
x Intel® Giga
LAN, HD Audio, 2 x SATA
32-bit PCI slot, PCIe mini card
& Mini-PCI sockets, 1 x LPT
6 x COM, 6 x USB2.0, DC 9V ~ 24V input or standard ATX P/S |
|
|
|
LV-67H |
Support
2nd Generation Intel®Core™ i7 / i5 / i3 Mobile processor |
|
|
Mini-ITX
support 2nd generation Intel®
Core™ i7 / i5 / i3 Mobile processor
Mobile Intel®
QM67 Express chipset, DDR3 1066/1333 MHz up to 16GB,
Onboard VGA,
LVDS, DVI, HD audio, 2 x Gigabit ethernet, 6 x SATA
1 x RS232/422/485, 5 x RS232, 10 x USB2.0, SPDIF, 8-bit GPIO,
PCI-Express X16 slot, 2
x Mini-PCIe sockets, 1 x SIM socket
Standard 24-pin ATX P/S or
Full range DC 9V ~ 24V input
|
|
|
|
LV-67G |
Support
2nd generation Intel®
Core™ i7 / i5 / i3 LGA1155 CPU |
|
|
Mini-ITX
support 2nd generation Intel®
Core™ i7 / i5 / i3 LGA 1155 processor
Intel® Q67 Express chipset, DDR3 1066/1333 MHz up to
16GB
Onboard VGA,
DVI, HD Audio, 2 x Intel®
Gigabit LAN, 4 x SATA with RAID
1 x RS232/422/485, 3 x RS232, 8 x USB2.0, SPDIF, 8-bit GPIO
PCI-Express X16 slot, Mini-PCIe
& Mini-PCI socket
|
| |
|
|
LV-67F |
Mini-ITX
support Intel® Core™ i7 / i5 / i3 Mobile with Intel® QM57 |
|
|
Intel®
Core™ i7 / i5 / i3 Mobile processor
Mobile Intel®
QM57 Express chipset, DDR3 800/1066 MHz up to 8GB,
Support VGA,
LVDS,
DVI, HD audio, 2 x Giga LAN, 6 x SATA with RAID 0/1/5/10
1 x RS232/422/485, 1 x RS232, 10 x USB2.0, SPDIF, 8-bit GPIO,
PCI-Express X16 slot, Mini-PCIe
& Mini-PCI sockets
Standard 20-pin ATX P/S or
Full range DC 9V ~ 24V input
|
|
|
|
LV-67E |
Onboard
Intel® Atom™ dual-core processor solution |
|
|
Onboard
Intel® Atom™ D525/D510 dual-core or D410/N450 single-core processor
Intel® ICH8M system
chipset
DDR2-667 SO-DIMM
SDRAM up to 2GB or
4GB
Onboard VGA, LVDS, 2 x
Intel® Giga LAN, HD Audio
6
x COM, 8 x USB2.0, 3 x SATA, 1 x LPT, 1 x SMBus 1
x PCI slot, 2 x PCIE mini card & 1 x Mini-PCI sockets DC
9V ~ 24V input or standard ATX power supply
|
|
|
|
LV-67D |
Intel®
Atom N270 for fanless Embedded computing |
|
|
Intel®
Atom N270 ( 1.6 GHz ) processor @ 533 MHz FSB
Intel® 945GSE &
ICH7M, DDR2 up to 2GB,
Onboard VGA, HDTV, 18-bit Dual
Channel LVDS or DVI
2 x Intel®
Gigabit Ethernet, HD audio, 2 x SATA
8 x USB 2.0,
6 x COM, SPDIF, GPIO
1 x PCI slot, 1 x PCI Express Mini card & 1 x Mini-PCI socket
|
|
|
|
LV-67C |
Intel®
Core™
i7 / i5 / i3 LGA1156 Platform |
|
|
Intel®
Core™ i7 / i5 / i3 / Pentium®
Desktop processor,
Intel®
BD82Q57 PCH (Platform Controller Hub), DDR3 1066/1333 MT/s up to 8GB,
Support VGA,
DVI, HD audio, 2 x Gbit LAN, GPIO, one x16 PCIe, 1 x Mini PCIe,
1 x MiniPCI, 4 x SATAII (RAID
0, 1, 5, 10), 1 x RS232/422/485, 3 x RS232,
1 x CDIN, 1 x IrDA, SMBus, 8
x USB2.0, SPDIF, 24-pin ATX power supply
|
|
|
|
LV-67B |
Intel® Core™ 2
Duo Mini-ITX Motherboard
|
|
|
Intel® Core™ 2 Duo
processor with socket-P @ 667/800/1066 MHz FSB
Intel® GM45
& ICH9M, DDR3 800/1066 MHz up to 8GB,
Onboard VGA, TV-out, 24-bit Dual
Channel LVDS.
PCI-Express
X16, Mini-PCI
and PCI Express Mini card socket.
Onboard 2 x Intel® Gigabit LAN,
7.1 channel HD Audio
RS232/422/485, IEEE1394, SPDIF, USB 2.0,
9V ~ 24V Full range DC input
or standard 20-pin ATX power supply. |
|
|
|
LV-67A |
Intel® Core™ 2
Quad / Core™2
Duo Mini-ITX
Motherboard |
|
|
Intel® Core
2 Quad / Core 2 Duo / Celeron Desktop, 800/1066/1333 MHz FSB, Intel®
Q45 & ICH10DO, DDRIII up to 4GB, Onboard VGA,
DVI, LVDS,
6 x
SATA with RAID, 1 x PCI slot & 1 x
Mini-PCI socket, 8 x USB 2.0,
2 x Gigabit LAN,
HD Audio, RS-232/422/485, IrDA, SPDIF, GPIO,
SMBus
|
|
|
|
LV-679
|
Intel® Core™ 2
Duo Mini-ITX Motherboard
|
|
|
Intel® CoreTM 2 Duo
( Merom )processor @ 800 MHz FSB
Intel® GME965
& ICH8M, DDRII 533 / 667 MHz up to 3GB,
Onboard VGA, 2 x DVI,
TV-out, 24-bit Dual
Channel LVDS.
2 x Mini-PCI
and 1 x PCI slot onboard
Onboard 2 x Intel® Gigabit LAN,
7.1 channel HD Audio
RS232/422/485, IEEE1394, SPDIF, USB 2.0,
8-bit GPIO, LPT, FDD, IrDA, CompactFlash socket
9V ~ 24V Full range DC input
or standard 20-pin ATX power supply. |
|
|
|
|
LV-678
|
Intel® Core™ 2
Quad / Core™2
Duo Mini-ITX
Motherboard
|
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop, 800/1066/1333 MHz FSB Intel®
Q35 & ICH9DO, DDRII up to 4GB, Onboard VGA
1 x PCI-Express slot & 1 x
Mini-PCI socket
Onboard 2 x Intel® Gigabit LAN,
HD Audio
RS-232/422/485, 8 x USB 2.0, IrDA, SPDIF, GPIO
|
|
|
|
|
LV-677
|
Intel® Core™Duo
/ Core™Solo Mini-IT express Motherboard
|
|
|
Intel® CoreTM 2 Duo / CoreTM
Duo processor , 533 / 667 MHz FSB
Intel® 945GME
& ICH7M, DDRII 533 / 667 MHz up to 3GB, Onboard VGA
18-bit Dual
Channel LVDS. 2 x Mini-PCI
and 1 x PCI-Express slot onboard
Onboard 1 x Intel® Gigabit LAN,
5.1 channel Audio
RS232/422/485, IEEE1394, SPDIF, USB 2.0,
8-bit GPIO, LPT, FDD, IrDA
8 V ~ 21 V Full range DC input
or standard 24-pin ATX power supply . |
|
|
|
|
LV-676
|
Intel® Core 2 Duo
/ Pentium D Mini-ITX Motherboard
|
|
|
Intel® Core
2 Quad / Core 2 Duo Desktop, 533/800/1066 MHz FSB Intel®
Q965 & ICH8DO, DDRII up to 4GB, Onboard VGA,
Optional LVDS or DVI interface, 1 x Mini-PCI and 1 x PCI slot
Onboard 2 x Intel® Gigabit LAN,
HD Audio
RS-232/422/485, IEEE 1394,
USB 2.0,
IrDA, SPDIF, GPIO
|
|
|
|
|
LV-675
|
Intel® Pentium M /
Celeron M Mini-ITX Motherboard
|
|
|
Intel® Pentium M / Celeron M,
400/533 MHz FSB .
DDR333 up to 1GB, Onboard VGA
Optional LVDS or DVI interface
S-video and Composite TV-out
connector,
2 x Mini-PCI and 1 x PCI socket
Onboard 1 x Intel® Gigabit LAN,
5.1 channel Audio
RS-232/422/485, IEEE 1394,
USB 2.0,
IrDA, SPDIF, GPIO
|
|
|
|
|
LV-674
|
Intel® Pentium D /
Celeron D Mini-ITX
express
Motherboard
|
|
|
Intel® CoreTM 2 Duo / Pentium D LGA775 processor (170 x 170mm)
533/800/1066MHz FSB, EM64T supported
Intel® 945G & ICH7R .2 x DDR2 533/667MHz SDRAM up to 2GB.
Intel® GMA950 technology. 4 x SATA II with 300MB/s transfer rate.
Realtek 7.1-CH High Definition Audio. Onboard GPIO port.
1 x Mini-PCI socket and 1 x PCI-Express slot.
4 x Giga LAN, 2 x IEEE 1394, 4 x USB 2.0, SPDIF.
2 x RS232, GPIO, IrDA.
|
|
|
|
LV-673
|
Intel® Pentium M / Celeron M Mini-ITX express
Motherboard
|
|
|
Intel® Pentium M / Celeron M processor (170 x 170mm )
Intel® 915GME & ICH6M
2 x DDR2 400/533 MHz SDRAM up to 2GB.
Intel® GMA900 technology.
Intel® High Definition Audio compliance.
1 x Mini-PCI socket and 1 x PCI-Express X16 slot.
CompactFlash and PCMCIA socket on solder side.
2 x Giga LAN, 2 x SATA, 6 x USB 2.0, SPDIF.
4 x RS232, GPIO, IrDA.
|
|
|
|
LV-672
|
Intel® Pentium 4 LGA775 Mini-ITX express Motherboard |
|
|
Intel® LGA775 Pentium 4 Prescott processor-based running
up to 3.6+ GHz with Intel® 915G & ICH6R, 2GB DDR2, 2x
Gigabit Ethernet port, 6 x USB 2.0, 2 x COM, 1 x SIR
AC97
3D Audio, 2 x IEEE1394 Interface, 8-bit digital I/O,
4 x SATA, PCI Express slot, Mini-PCI socket
|
| |
|
LV-671CM6
|
Intel®
ULV Celeron M 600 MHz for low power solution |
|
|
Mini-ITX Celeron M Embedded Motherboard (170 x 170 mm)
Onboard Intel® Celeron M 600 MHz uFCBGA CPU
Intel® 852GM and ICH4 Chipset
1 GB DDR 266 SDRAM
Intel® 852GM GMCH Built-in Extreme Graphics with 256-bit 3D Engine
Intel® Dynamic Video Memory up to 64MBytes
Onboard 40-pin
LVDS
LCD connector
Onboard Intel® 82541PI Gigabit Ethernet controller
Onboard PCMCIA Type I/II slot
Onboard Intel® ICH4 Hi-Speed USB 2.0 Interface
Onboard 5.1-Channel
|
|
|
LV-671
|
Mobile Pentium M Motherboard for Low Power & LVDS Solution |
|
|
Mini-ITX Pentium M Embedded Motherboard (170 x 170 mm)
Intel® mPGA478 Pentium M @ 400 MHz FSB
Intel® 855GME and ICH4 Chipset
1 GB DDR 266/333 DDR SDRAM
Intel® 855GME GMCH Built-in Extreme Graphics with 256-bit 3D Engine
Intel® Dynamic Video Memory up to 64MBytes
Onboard 40-pin
LVDS
LCD connector
Onboard Intel® 82541PI Gigabit Ethernet controller
Onboard PCMCIA Type I/II slot
Onboard Intel® ICH4 Hi-Speed USB 2.0 Interface
Onboard 5.1-Channel
|
|
|
|
|
LV-669
|
VIA
C7 processor with CN700 & VT8237
|
|
|
Mini-ITX VIA C7 Embedded Motherboard
VIA CN700 and VT8237R+ Chipset
Optional onboard 256 MB DDR
SDRAM and one DDR DIMM up to 1GB
Onboard VGA and optional LVDS
or DVI interface
2 x Realtek Gigabit LAN,
2 x SATA ports
Mini-PCI and PCI slot, CompactFlash
socket
4 x serial ports, 6 x USB 2.0,
LPT, IEEE 1394, AC97 Audio
8 ~ 24 full range DC input,
onboard 4-pin 12V DC connector
|
| |
|
|
|
VIA C3 & MPEG-4 Mini-ITX Motherboard
|
|
|
Mini-ITX Embedded Motherboard (170 x 170 mm)
VIA CN400 with Embedded C3 1.0GHz CPU @ 133 MHz FSB
Support 1GB DDR266/333/400 SDRAM
Integrated VIA MPEG-4 Accelerator and integrated UniChrome™ 2D/3D graphics
Onboard Dual LAN, Mini-AGP, SATA, 3 x IEEE1394, 4 x COM
Onboard AC97 Audio, CompactFlash Socket
|
| |
|
|
|
Mini-ITX with AMD Geode LX 800 Solution
|
|
|
AMD Geode LX
800 process-based Min-ITX running at 500+ MHz
Mini-ITX
Motherboard based on AMD LX800, CS5536, 1GB DDR DIMM &
onboard
256MB DDR optional, IDE, AC97
Audio, Giga LAN, 4 x USB2.0,
2
x COM, GPIO, LVDS & TTL LCD Interface, IEEE1394, Printer port,
Mini-PCI
& PCI socket, CF, DC 8~24V or ATX P/S
|
| |
|
LN-D70
|
Nano-ITX Embedded with Intel® Celeron™ processor J1900
/ N2930 and Atom™ processor E3845
|
|
|
Nano-ITX embedded Intel® Celeron™ J1900 / N2930 &
Atom™ E3845 Mobile processor.
Support for one DDR3L SO-DIMM 1066/1333 MHz up to 8GB,
Onboard DisplayPort, DVI, CRT, 2 x LVDS, HD Audio,
1 x Intel® Gigabit LAN, 2 x SATAII, 2 x SATAIII,
Onboard 1 x Intel® Gigabit LAN,
5.1 channel Audio
5 x RS232,
1 x RS232/422/485, 3 x USB2.0, 1 x USB3.0, 8-bit GPIO,
|
|
|
| |
|
BackToTop |
Pico-ITX Embedded Motherboard
|
|
NEW |
|
|
LP-17C |
Pico-ITX with
Intel®
Atom™
Amston Lake
Processor X Series |
|
 |
Pico-ITX
with
Intel® Atom™
Amston Lake Processor X Series.
Intel®
UHD Graphics,
Support one DDR5
4800 SO-DIMM up to 32GB,
Onboard HDMI, DisplayPort ++,
Type-C (DP Alt.Mode)
2 x Intel®
I226 2.5 Gigabit LAN,
HD Audio, SATA3, 1 x COM, 2 x USB2.0,
1 x USB3.2 Gen2,
DC input
12V ± 5%,
1 x
M.2 (key E), 1 x
M.2 (key M), 1 x GPIO. |
|
NEW |
|
|
LP-17B |
Pico-ITX with
Intel®
Core™
Ultra
Meteor Lake series
Processors |
|
 |
Pico-ITX
with
Intel® Core™
Ultra Meteor Lakeseries Processors.
Intel®
Graphics,
Support one DDR5
5600 SO-DIMM up to 48GB,
Onboard HDMI, DisplayPort ++,
Type-C (DP Alt.Mode)
1 x Intel® I226-LM 2.5 Gigabit LAN,
1 x Intel® I226-V 2.5 Gigabit LAN,
HD Audio, SATA3, 1 x COM, 2 x USB2.0,
1 x USB3.2 Gen2,
DC input
12V ± 5%,
1 x
M.2 (key E), 1 x
M.2 (key M), 1 x GPIO. |
|
|
|
|
LP-17A |
Pico-ITX with
Intel® 12th & 13th Gen
U Processor |
|
 |
Pico-ITX
with
Intel® 12th &13th Gen
U Processors.
Intel®
UHD
Graphics,
Support one DDR5
4800 SO-DIMM up to 32GB,
Onboard HDMI,
Type-C (DP Alt.Mode)
1 x Intel®
2.5 Gigabit LAN,
1 x Intel® Gigabit PHY LAN,
HD Audio, SATA3, 1 x COM, 2 x USB2.0,
2 x USB3.2 Gen2,
DC input
12V ± 5%,
1 x
M.2 (key E), 1 x
M.2 (key M), 1 x GPIO. |
|
|
|
|
LP-179 |
Pico-ITX with
Intel® Tiger Lake
UP3 Processor |
|
 |
Pico-ITX
with
Intel® Tiger Lake UP3
Processors.
Intel®
UHD
Graphics,
Support one DDR4
3200 SO-DIMM up to 32GB,
Onboard DisplayPort, HDMI,
1 x Intel®
2.5 Gigabit LAN,
1 x Intel® Gigabit PHY LAN,
HD Audio, SATA3, 2 x COM, 2 x USB2.0,
2 x USB3.2 Gen2, SMBus,
DC input
12V ± 5%,
1 x
M.2 (key E), 1 x
M.2 (key M). |
|
|
|
|
LP-178 |
Pico-ITX with
Intel®
Whiskey Lake
U Processor |
|
 |
Pico-ITX
with
Intel® Whiskey Lake U Processors.
Intel® integrated HD
Graphics,
Support one DDR4
2400 SO-DIMM up to 32GB,
Onboard optional DisplayPort, HDMI,
1 x Intel® Gigabit LAN,
1 x Intel® Gigabit PHY LAN,
HD Audio, SATA3, 2 x COM, 2 x USB2.0,
2 x USB3.1 Gen2, SMBus, LPC,
DC input
12V ± 5%, 1 x
M.2 (key E). |
|
|
|
|
LP-177 |
Pico-ITX with Intel®
Apollo Lake Series
processor
|
|
 |
Pico-ITX
with Intel® Apollo Lake
Series processor.
Intel® integrated HD
Graphics,
Support one DDR3L 1866 SO-DIMM up to 8GB,
Onboard optional DisplayPort, HDMI, LVDS, 2 x Intel® Gigabit LAN,
HD Audio, SATA3, 2 x COM, 2 x USB2.0,
2 x USB3.0, SMBus, LPC,
DC input
5V ± 5%,
1 x PCIe mini card
support mSATA. |
|
|
|
|
LP-176 |
Pico-ITX with Intel®
Braswell Series Mobile
processor
|
|
 |
Pico-ITX with Intel® Braswell
Series Mobile processor.
Intel® integrated HD
Graphics,
Support one DDR3L 1600 SO-DIMM up to 8GB,
Onboard optional DisplayPort, HDMI, LVDS, Intel® Gigabit LAN,
HD Audio, SATA3, 2 x COM, 2 x USB2.0,
2 x USB3.0, SMBus, LPC,
DC input
5V ± 5%, 1 x PCIe mini card
support mSATA, |
|
|
|
|
LP-175 |
Pico-ITX with Intel®
Skylake / Kaby Lake (6th /
7th) Core™ U-series Mobile
processor
|
|
 |
Pico-ITX with Intel®
Skylake / Kaby Lake (6th/7th) Core™ U-series Mobile processor.
Intel® Gen 9 integrated HD
Graphics,
Support one DDR4
1866/2133 SO-DIMM up to 16GB,
Onboard HDMI, LVDS,
optional DisplayPort/VGA, Intel® Gigabit LAN,
HD Audio, SATA3, 2 x COM, 2 x USB2.0,
2 x USB3.0, LPC,
DC input
5V ± 5%, 1 x PCIe
mini card support mSATA |
| |
|
|
LP-174
|
Pico-ITX with Intel® Broadwell (5th) / Haswell (4th) Core™ U-series Mobile
processor
|
|
|
Pico-ITX with Intel® Broadwell(5th)
/ Haswell (4th) Core™ U-series Mobile processor.
Intel® 5th
/ 4th Gen integrated HD
Graphics,
Support one DDR3L 1333/1600 SO-DIMM up to 8GB,
Onboard DisplayPort, DVI, LVDS, Intel® Gigabit LAN,
HD Audio, SATA3, 2 x COM, 2 x USB2.0, 2 x USB3.0,
SMBus, LPC,
DC 9~30V input, 1 x PCIe
mini card support mSATA
|
| |
|
|
LP-173
|
Pico-ITX with Intel® Celeron™ processor J1900 / N2930 and Atom™ processor E3845
|
|
|
Pico-ITX with Intel® Celeron™ J1900 / N2930,
Atom™ E3845 Intel® Clear Video integrated HD Graphics Technology,
Support one DDR3L 1066/1333 SO-DIMM up to 8GB,
Onboard HDMI, LVDS,
VGA,
Intel® Gigabit LAN, HD Audio, SATAII,
2 x COM, 3 x USB2.0, 1 x USB3.0, GPIO, LPC, DC 6~30V input,
1 x PCIe mini card
support mSATA
|
|
|
|
|
LP-180
|
Pico-ITX
with
onboard AMD Dual-core T56N 1.65 GHz
|
|
|
Onboard AMD
Dual-core T56N 1.65 GHz
AMD A55E FCH
chipset, DDR3 1066/1333 MHz up to 4GB,
Support
VGA, LVDS or DVI, HD audio, Intel®
Giga LAN,
1 x SATAII, 2
x RS232, 4 x USB2.0, LPC
Mini-PCIe socket, DC 5V input
|
|
|
|
|
LP-172
|
Pico-ITX
with Intel® Atom™processor D2550 / N2800
|
|
|
Pico-ITX
with Intel® Atom™
processor D2550 or N2800
Intel® NM10 Express chipset
DDR3-800/1066 SO-DIMM
up to 4GB
Onboard VGA, LVDS, Intel® Giga
LAN, HD Audio, SATA
PCIe mini card socket, 2 x COM, 4 x USB2.0, DC 5V input
|
|
|
|
|
LP-171
|
Pico-ITX
with Intel® Atom™ Solution
|
|
|
Pico-ITX
with Intel® Atom™
processor
Intel® SCH US15WP chipset
DDR2-667 SO-DIMM
SDRAM up to 2GB
Onboard VGA or DVI,
LVDS, Intel® Giga LAN, HD Audio
2 x COM, 2 x USB2.0, DC 12V input
|
|
LP-170
|
Pico-ITX
with Intel® Atom™ dual-core Solution
|
|
|
Pico-ITX
with Intel® Atom™
D525/D510 dual-core processor
Intel® ICH8M system chipset
DDR2-667 SO-DIMM
SDRAM up to 2GB
Onboard VGA, LVDS, Intel®
Giga LAN, Audio, COM, USB2.0
|
|
|
|
|
LP-150 |
Pico-ITX with
Rockchip RK3128
Quad-core Cortex-A7 |
|
|
Pico-ITX
with
Rockchip RK3128 Quad-core Cortex-A7@1.3
GHz .
Graphics for
3D : High performance OpenGL ES1.1 and 2.0,
OpenVG1.1, 2D : Bit Blit with Strength Blit, Simple Blit and Filter
Blit.
Onboard
512MB DDR3 SDRAM,
Flash Storage
one
8GB
onboard
eMMC,
one Micro SD card slot,
Built in audio codec for Line-in, and
Head Phone out Interface,
Integrated HDMI 1.4 output up to 1080P@60Hz,
Embedded
one
USB Host 2.0
ports and one USB 2.0 OTG port |
|
|
BackToTop
|
Industrial ATX Motherboard
|
|
| |
|
|
AS-C7A
|
Skylake / Kaby Lake Intel® 6th
/ 7th Gen Core™ S-series and Xeon®
E3-1200 v5 Processor LGA1151 CPU ATX
industrial motherboard |
|
|
Industrial ATX desktop Skylake / Kaby Lake Intel® 6th / 7th Core™ S-series and Xeon®
FCLG1151 package. Support for four DDR4 DIMM 1866 / 2133 MHz to 64GB.
Support Audio, COM, DVI, LVDS,
HDMI, CRT, and optional Display Port.
1 x Intel® Gigabit PHY LAN, 1 x Intel® Gigabit LAN, 6 x USB3.0, 4 x USB2.0, 4 x SATA,
PCI-Express X16 & X4
& X1 slot, 4 x PCI slots, 2 x Mini-PCIe sockets
|
|
ME-C79
|
Intel® 4th Generation Intel®Core™ i7 / i5 / i3 & Celeron 2002E
Mobile processor MicroATX motherboard |
|
|
4th Generation Intel® Core™ i7 / i5 / i3 & Celeron 2002E CPU with
Intel® QM87 Express chipset,
4 x DDR3L DIMM 1333/1600 MHz up to 32GB. Support Display Port,
CRT, DVI, LVDS, 2 x Gigabit LAN, 6 x USB3.0, 4 x USB2.0, 4 x SATA,
PCI-Express X16 & X4 slot ,
2 x PCI slots , Mini-PCIe
& Mini-PCI sockets
|
| |
|
|
MS-C78
|
Intel® Core™ i7 / i5 / i3 / Celeron / Pentium LGA1150 MicroATX motherboard |
|
|
Support 4th Generation Intel® Core™ i7 / i5 / i3 , Celeron / Pentium LGA1150 CPU
with Intel® Q87 Express chipset,
4 x DDR3/DDR3L DIMM 1333/1600 MHz up to 32GB.
Support Display Port, CRT, DVI, LVDS, 2 x Gigabit LAN, 6 x USB3.0,
6 x USB2.0, 4 x SATA, 1 x PCIe x16 slot, 1 x PCIe x4 slot,
2 x PCI slot, 1 x mini PCI slot, 1 x mSATA (Only for SATA3),1 x RS232/422/485,
5 x RS232, 1 x PS/2, SMBUS, IrDA, GPIO, HD Audio, LPT ,
LPC(TPM)
|
| |
|
|
AS-C76
|
Support
3rd Generation Intel®Core™ i7 / i5 / i3 LGA1155 CPU
ATX motherboard
|
|
|
3nd generation Intel®
Core™ i7 / i5 / i3 & Pentium LGA1155 desktop processor
Intel® Q77 Express chipset, DDR3
1066/1333 MHz up to 32 GB,
Support VGA,
DVI, HD audio, 2 x Giga LAN, 6 x SATA, TPM,
1 x RS232/422/485, 5 x RS232,
8 x USB2.0, 4 x USB3.0, SPDIF, 8-bit GPIO
PCI-Express X16 & X4 slot ,
5 x PCI slots , Mini-PCIe
& Mini-PCI sockets
|
|
|
|
|
MS-C75
|
Intel®
3rd Generation Intel®Core™ i7 / i5 / i3 Mobile processor MicroATX motherboard
|
|
|
3nd generation Intel®
Core™ i7 / i5 / i3 & Celeron Mobile processor
Mobile Intel®
QM77 Express chipset, DDR3 1066/1333/1600 MHz up to 16 GB,
Support VGA,
LVDS, DVI, HD audio, 2 x Giga LAN, 6 x SATA
1 x RS232/422/485, 5 x RS232,
6 x USB2.0,
4 x USB3.0, SPDIF, 8-bit GPIO, LPT
PCI-Express X16 & X4 slot ,
2 x PCI slots , Mini-PCIe
& Mini-PCI sockets
|
|
|
|
|
AS-C74
|
Intel®
Core™
i7 / i5 / i3 LGA1155 ATX motherboard
|
|
|
2nd generation Intel®
Core™ i7 / i5 / i3 & Pentium LGA1155 desktop processor
Intel® Q67 Express chipset, DDR3
1066/1333 MHz up to 32 GB,
Support VGA,
DVI, HD audio, 2 x Giga LAN, 6 x SATA, 1 x LPT
1 x RS232/422/485, 5 x RS232,
12 x USB2.0, SPDIF, 8-bit GPIO
PCI-Express X16 & X4 slot ,
5 x PCI slots , Mini-PCIe
& Mini-PCI sockets
|
|
|
|
|
MS-C73
|
Intel®
Core™
i7 / i5 / i3 PGA988B MicroATX motherboard
|
|
|
2nd generation Intel®
Core™ i7 / i5 / i3 & Celeron Mobile processor
Mobile Intel®
QM67 Express chipset, DDR3 1066/1333/1600 MHz up to 16 GB,
Support VGA,
LVDS, DVI, HD audio, 2 x Giga LAN, 6 x SATA
1 x RS232/422/485, 5 x RS232,
10 x USB2.0, SPDIF, 8-bit GPIO, LPT
PCI-Express X16 & X4 slot ,
2 x PCI slots , Mini-PCIe
& Mini-PCI sockets
|
|
|
|
|
MS-C72
|
Intel®
Core™
i7 / i5 / i3 LGA1156 MicroATX motherboard
|
|
|
Intel®
Core™ i7 / i5 / i3 / Pentium®
Desktop processor,
Intel®
BD82Q57 PCH (Platform Controller Hub), DDR3 1066/1333 MT/s up to 16 GB,
Support VGA,
DVI, HD audio, 2 x Gbit LAN, GPIO, PCIe X16/X4, 1x Mini PCIe,
1 x MiniPCI, 6 x SATAII (RAID
0, 1, 5, 10), 1 x RS232/422/485, 5 x RS232,
1 x CDIN, 1 x IrDA, SMBus, 10 x USB2.0,
SPDIF, LPT , FDD, ATX PSU support
|
|
|
|
|
MS-C71
|
Intel®
Core™
i7 / i5 / i3 PGA988A MicroATX motherboard
|
|
|
Intel®
Core™ i7 / i5 / i3 Mobile processor
Mobile Intel®
QM57 Express chipset, DDR3 800/1066 MHz up to 8.0 GB,
Support VGA,
LVDS, DVI, HD audio, 2 x Giga LAN, 8 x SATA , Compactflash
1 x RS232/422/485, 5 x RS232,
12 x USB2.0, SPDIF, 8-bit GPIO, LPT
PCI-Express X16 & X4 slot ,
2 x PCI slots , Mini-PCIe
& Mini-PCI sockets
|
|
|
|
|
P4ELA
|
Intel®
Core™2 Quad / Core™Duo MicroATX Motherboard
|
|
|
Intel®
CoreTM
2 Quad/CoreTM 2 Duo/Celeron, FSB 800/1066/1333MHz,
LGA775,
Intel®
Q45 & ICH10DO, DDRIII 800/1066 SDRAM up to
8GB, Onboard VGA,
Onboard 2 x Intel® Gigabit LAN,
HD Audio, 12 x USB, 6 x SATAII with RAID,
6 x
COM, 1x ISA, 2 x PCI, 1 x mini-PCI, one x16 PCI-E & one
x4 PCI-E
|
|
|
|
|
P4BWA
|
Intel®
Core™2 Quad / Core™2 Duo ATX Motherboard
|
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop , 533/800/1066 MHz FSB Intel®
Q965 & ICH8DO , DDRII up to 8.0 GB , Onboard VGA ,
Onboard 2 x Intel® Gigabit LAN ,
HD Audio ,
10 x USB 2.0 , 6 x SATAII , 6 x
COM ports ,
1 x PCI-Express X16 , 1 x PCI-Express
X4 ,
1 x Mini-PCI , 4 x PCI slots ,
2 x ISA slots
|
|
|
|
|
P4LA
|
Intel® Core™2 Dup
/Pentium D Industrial ATX Motherboard
|
|
.jpg)
|
LGA775 for Intel® CoreTM
2 Duo / Pentium D CPU
FSB 533 / 800 / 1066 MHz .
Intel® 945G & ICH7R Chipset
.
Onboard VGA , Gigabit LAN , HD
Audio , SATA II
6 COM , 6 USB2.0 , SPDIF ,
8-bit GPIO , LPT , IrDA
CompactFlash and DOC socket .
PCI-Express X16 / X4 / X1, 4 PCI and 1 ISA
|
|
|
|
|
PMSA
|
Intel®
Core Duo MicroATX Motherboard
|
|
|
Intel® CoreTM
2 Duo ( Merom) @
800 MHz FSB .
Intel® GME965 &
ICH8M Chipset .
DDRII 533/667 MHz up
to 3.0 GB .
Onboard VGA , LVDS ,
HDTV ,
2 x Gigabit LAN , 6
COM , 10 USB2.0 , SATA , GPIO
LPT , SPDIF , IrDA ,
FDD , HD Audio , 2 IEEE1394
Mini-PCI & CompactFlash
Socket ,
PCI-Express X16 , PCI-Express
X1 , 2 x PCI and ISA slots
|
|
BackToTop |
|
|
|
Computer
On Moduleus |
|
|
|
|
QE-E71 |
Onboard Intel® 5th/4th Gen Core™ U-series Processor |
|
|
QSeven CPU Module with onboard Intel® 5th/4th Gen Core™ U-series Processor,
Support DDR3L 1600 MHz 2GB / 4GB on board
memory,
Support 2 x DDI, 1 x eDP for Triple display, two Serial ATA3,
Support two USB3.0 , two USB 2.0, four PCIe x1,
Power supply: DC Input 5V & 5VSB & RTC
.
|
| |
|
|
QE-E70 |
QSeven CPU Module with Intel® Celeron™ processor J1900 / N2930 and Atom™ processor E3845 |
|
.jpg) |
QSeven CPU Module with Intel® Celeron™ processor J1900 / N2930
and Atom™ processor E3845.
Support DDR3L 1600 MHz 2.0 GB or 4GB on board memory.
Support two eDP, VGA, HD Audio interface, two Serial ATAII ,
Support one USB3.0 , four USB 2.0, four PCIe x1,
Power supply: 5V , 5VSB
|
|
|
|
|
CES-471 |
Intel® Core™ 2 Duo COM Express Module |
|
|
Intel® CoreTM 2 Duo Mobile processor @ 533/800 MHz FSB
Intel® GME965 & ICH8M , DDRII 533 / 667 MHz up to 2.0 GB
Support VGA , HDTV , 24-bit Dual Channel LVDS ,
Support 1 x Gigabit LAN , 7.1 channel HD Audio
Support x16 & x1 PCI-Express slot and 4 x PCI slot , 8 x USB 2.0
Power supply: 12V , 5VSB
|
|
|
|
|
CES-470E |
Intel® Pentium M / Celeron COM Express Module
|
|
|
Intel® Pentium M / Celeron M processor
Intel® 915GME & ICH6M
1 x DDR2 400/533 MHz SO-DIMM up to 1GB.
Intel® GMA900 technology .
Support VGA , HDTV , 18-bit Dual Channel LVDS ,
Support 1 x Fast LAN , AC97 or 7.1 channel HD Audio
Support x16 & x1 PCI-Express slot and 4 x PCI slot , 8 x USB 2.0
Power supply: 12V , 5VSB
|
|
|
|
|
ES-270E |
Intel® Core™Duo / Core™Solo Mini-ITX COM Express Module |
|
|
Intel® CoreTM 2 Duo / CoreTM Duo processor , 533 / 667 MHz FSB
Intel® 945GME & ICH7M , DDRII 533 / 667 MHz up to 2.0 GB
Support VGA , 18-bit & optional 24-bit Dual Channel LVDS .
Support 1 x Gigabit LAN , 5.1 channel AC97 Audio
Support 2 x serial ports , 4 x USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA
Power supply: 5V , 5VSB
|
| |
|
|
BackToTop |
|
