TAIPEI, TAIWAN, 10. 21,
COMMELL UNVEILED LP-17A & LV-6715
BASED ON INTEL ALDER LAKE
Computer Inc .(COMMELL), the worldwide leader of Industrial Single
Board Computers, unveiled LP-17A Pico-ITX & LV-6715 Mini-ITX based
on Intel® 12th Gen. FCBGA1744 ˇ§Alder Lakeˇ¨ U series and H series.
The LP-17A Pico-ITX
is designed for the 12th generation Intel® Alder Lake U Processor -
Core™ i7-1265UE, Core i7-1265UE has 12MB cache up to 4.7 GHz, and up
to 10 cores/12 threads.
Mini-ITX is designed for the 12th generation Intel® Alder Lake H
Processor - Core™ i7-12800HE, Core i7-12800HE has 24MB cache up to
4.6 GHz, Intel's processor supports DDR5 memory.
officially supported memory speed is 4800 MHz. The LP-17A7 features
one DDR5-4800 SO-DIMM slot for up to 32GB of memory. LV-6715H7
features two DDR5-4800 SO-DIMM slot for up to 64GB of memory.
LV-6715 Intel Alder
Lake-H Features up to 14 cores/20 threads, it delivery up to 2.47
faster graphic performance than predecessor, with Intel® Iris Xe
Graphics up to 96 graphics EUs for enable high- performing AI
acceleration and visuals across IoT deployments.
LP-17A7 Displays one
HDMI, one Type-C (DP Alt. Mode) onboard, and adds ADP-3460 module to
support LVDS interface. LP-17A7 offers 2 x USB2.0, 2 x USB3.2 Gen2,
and 1 x SATAIII, equipped with one Gigabit Ethernet and one 2.5Gb
Ethernet (1 x Intel® I219-LM Gigabit PHY LAN and 1 x Intel® I226-LM
2.5 Gigabit LAN), and comes with internal 1 x RS232/422/485, 1 x HD
Audio, 1 x GPIO, 1 x M.2 Key M 2280 for support PCIe Gen4 and SATA,
1 x M.2 Key E 2230 for Wi-Fi & BT module, Standard 12V DC input.
LVDS, two HDMI and two DP ports onboard, one internal HDMI/DVI
header, up to four displays can be controlled
simultaneously.LV-6715H7 offers the features as 4 x USB2.0, 4 x
USB3.2 Gen2 and 2 x SATAIII, equipped with one Gigabit Ethernet, and
one 2.5Gb Ethernet by RJ45 (1 x Intel® I219-LM Gigabit PHY LAN and 1
x Intel® I226-LM 2.5 Gigabit LAN), one internal 2.5Gb Ethernet by
Pin-header (Intel® I226-LM 2.5 Gigabit LAN), 2 x RS232/422/485 and 4
x RS232, 1 x 8bits GPIO, 1 x HD Audio, 1 x SMBus, 1 x M.2 Key M 2280
for support PCIe Gen4 device such as NVMe, 1 x M.2 Key E 2230 for
Wi-Fi & BT module, 1 x MiniPCIe(support mSATA), 1 x PCIe X16 slot to
support PCIe Gen4 X8, Standard 24-Pin ATX or 4-Pin 9~35V DC input.
