Product > Digital Signage > MSB05

..........................................................................................................................................

MSB05
Digital Signage

      MSB05








Specifications
Operating System Android 4.4.4
Web server nginx
CPU 1.2G/4 core
DRAM 512M
Flash 8G
Storage 32G/64G/128G SD
GPS uBlox, 9600bps
USB 2.0
Wi-Fi (Optional) 802.11 a/b/g/n/ac
Display (HDMI/CVBS) 720P
Input DC 9~36V with power protection
Power Consumption 24V, 300mA(operation)/1mA(idle)
Operating Temp. -20~85℃
Dimension 204*129*43mm
Weight 940g
Real Time Clock for auto-wakeup function
Onboard 5G WiFi (Optional) for content update
Onboard LTE/ LTE Cat M1 (Optional) for content update/ location tracking



Ordering Information
MSB05: 720P HDMI, RJ45 LAN, 32G SD, Standalone.
MSB05-W: 720P HDMI, RJ45 LAN, 32G SD, WiFi,
Cloud system management.
MSB05-L: 720P HDMI, RJ45 LAN, 32G SD,
4G LTE, Cloud system management.
MSB05-LW: 720P HDMI, RJ45 LAN, 32G SD, WiFi + 4
G LTE, Cloud system management.

Nanoair P1-USB: Water Ion Air Purifier with 120cm USB Type A cable.
Nanoair P1-ACC: Water Ion Air Purifier with 141cm USB Type A cable.
