Board
Size 114
x 95 mm
CPU
Type
Support
VIA Luke CoreFusion processor with 1.0 GHz or 800/533 MHz .
Chipset
VIA
Luke and VT8237R .
Memory
Type
1
x 200-pin DDR SO-DIMM support up to 2.0 GB .
VGA
Interface Integrates
UniChrome Pro IGP 2D/3D Graphics core . LVDS
Interface 24-bit
Dual channel LVDS interface. Inverter connector onboard . Enhanced
IDE UltraATA/100
IDE up to 2 ATAPI . Series
ATA Integrated
Series ATA/RAID controller facilities high-speed data transfer up
to 150MB/s for each of 2 ports . LAN
Interface 10/100Mbps
Ethernet port provide by VIA VT6103 . Audio VIA
VT8237R built -in AC97 3D audio controller with ALC202A to
support 2 channel audio. USB 4
x Hi-Speed USB2.0 ports . I/O
ports 2
x RS232 , Parallel , IrDA , FDD , PS/2 keyboard/mouse . PCI
Support
PCI bus interface . Digital
I/O Support
8-bit digital I/O . Watchdog 256-level
generates reset programmable watchdog timer .
|
